Panel PCs (PPCs)

  • Open Frame Panel PC
  • Closed Frame Panel PC
  • Rugged Panel PC
  • Wide Temperature Panel PC
  • Fanless Panel PC
  • ARM or x86 Panel PC

EMAC is a global leader in industrial automation and HMI Panel PCs.  We provide Panel PCs for embedded automation computers, automation controllers, remote i/o modules, and custom data acquisition solutions.

EMAC's Panel PCs are available ready to run with the Operating System installed on a flash disk or hard drive. Apply power and watch either the Windows or Linux User Interface appear on the vivid color LCD. Interact with the PPC using the responsive integrated touchscreen. Everything works out of the box, allowing you to concentrate on your application, rather than building and configuring device drivers. Just Write-It and Run-It.

Contact the EMAC Panel PC Sales Department for details on Sunlight Readable Panel PC, IP65 Panel PC, IP67 Panel PC, Panel PCs suitable for the Outdoors, Wide Voltage Panel PC, and/or Low Power Consumption Panel PC specifications. While the selection below is a starting point, EMAC can offer many other Panel PC configurations, with the options of customization to best fit the project. Please contact us with the project needs if the right system is not easily found.

PMX-090T303

Additional Options

Receive consultation or product quotes from our sales staff, today.

Request a quote

All PPCs

Product # Video/ Touchscreen CPU Memory Serial Ports Disk Interfaces Bus Dimensions Other I/O
DEV-SOM36PPC-04-5D36 Panel PC Front 4.3 " TFT Color WQVGA LCD, 480 x 272, 4-Wire Analog Resistive Atmel ARM Cortex A5 ATSAMA5D36 512 MB of DDR2 SDRAM, 4GB eMMC Flash Onboard 2x RS-232, 1x RS-232/422/485 with Auto RS485, 2x USB 2.0, CAN, SPI MicroSD None Open Frame PPC4.8" ×3" ×1.2" 10/100 DP83640 IEEE 1588 PTP LAN & GbE Ethernet, Audio, 16x GPIO
PPC-04-3354PPC-04-3554 Panel PC Front 4.3 " TFT Color WQVGA LCD, 480 x 272, 4-Wire Analog Resistive TI ARM Cortex A8 based Processor AM3354, 512 MB of DDR3 SDRAM, 4GB eMMC Flash Onboard 3x RS-232 with handshaking, 1x RS-232/422/485 with Auto RS485, high-speed SPI with chip selects, I2C SDIO SDHC/ MMC Flash Disk None Open Frame PPC4.8" ×3" ×1.2" 10/100 Ethernet, Audio, 16x GPIO
HMI-043THMI-043T x86 Panel PC 4.3 " TFT, Color WQVGA LCD, 480 x 272, 4-Wire Analog Resistive DMP Vortex86EXm 400 MHz Up to 256 MB DDR3 RAM Onboard 1x RS-232, 485 or CAN SD Slot or up to 2GB eMMC NAND Flash Memory Onboard N/A Enclosed PPC4.58" ×3.71" ×1.35" Ethernet, POE, HF RFID/NFC, 1x USB 2.0
HMI-043T-OPPC-043T 4.3" Open Frame 4.3” WQVGA TFT LCD, 4-wire Analog Resistive Touch Screen DMP Vortex86EXm 400MHz up to 256MB DDR3 onboard 1x RS-232, 2x RS-485, 1xCAN SD Slot or up to 2GB eMMC NAND Flash Memory Onboard Expansion slots Open Frame PPC4.15" ×2.65" ×0.54" Ethernet, 2x USB2.0, 1x 8-bit GPIO
PDX-057TPDX-057 Panel PC 5.7" TFT Color LCD, 640 x 480, Analog Resistive Vortex86DX Fanless CPU, 1 GHz Up to 512MB RAM 1x RS-232/422/485, 2x USB 2.0 1 IDE, Compact Flash Micro SD Mini PCI Enclosed PPC6" ×4.4" ×1.2" RDC 6040 10/100 Base-T Ethernet2x USB 2.0
PMX-057TPMX-057 5.7" TFT Color LCD, 640 x 480, Analog Resistive Vortex86MX+ Fanless CPU 1GHz Up to 1GB DDR2 onboard 1x RS-232/422/485, 2x USB 2.0 1x RS232/422/485 1 IDE, Compact Flash Micro SD Mini PCI Enclosed PPC6" ×4.4" ×1.2" 10/100 Base-T Ethernet, 2x USB 2.0, Audio
PDX2-057TPDX2-057T Enclosed Panel PC 5.7" TFT LCD with Resistive Touch Screen DM&P Vortex86DX2 - 933MHz Up to 2GB DDR2 Onboard 1x RS-232/422/485, 2x USB 2.0 CF Card or Micro SD slot Enclosed PPC5.98" ×4.41" ×1.3" 1x HD Audio-Realtek ALC262 CODEC, 1x 10/100 Ethernet Integrated, 2x USB 2.0 Ports
PEX-057TPEX-057T Panel PC 5.7" VGA TFT LCD with Resistive Touch Screen DM&P Vortex 86EX Onboard 400 MHz 1 GB DDR3 Onboard 1x RS-232/422/485 & 2x USB 2.0 MicroSD Slot Enclosed PPC5.98" ×4.41" ×1.3" 1x HD Audio-Realtek ALC262 CODEC, 1x 10/100 Ethernet Integrated, 2x USB 2.0 Ports
PDX3-057TPDX3-057T Panel PC 5.7" VGA TFT LCD with Resistive Touch Screen DM&P Vortex86DX3-Fanless Onboard 1GHz Up to 2GB DDR3 Onboard 1x RS-232/422/485, 2x USB 2.0 CF Card or Micro SD slot Enclosed PPC5.98" ×4.41" ×1.3" 1x 10/100 Ethernet Integrated, 2x USB 2.0 Ports, Audio HD Audio-Realtek ALC262 CODEC
PPC-07-3354PPC-07-3354 Panel Front 7" TFT Color WVGA LCD, 800 x 480, 4-Wire Analog Resistive TI ARM Cortex A8 based Processor AM3354 1.0GHz 512 MB of DDR3 SDRAM, 4GB eMMC Flash Onboard 3x RS232 & 1x RS232/422/485 Port, 2x USB 2.0 Host, 1x USB 2.0 OTG SDIO SDHC/ MMC Flash Disk Open Frame PPC7.55" ×4.15" ×1.5" 1x 10/100 BaseT Ethernet, WiFi 802.11 b/g/n, I2S Audio
PPC-07-5D36PPC-07-A5D3 Panel Front 7" TFT Color WVGA LCD, 800 x 480, 4-Wire Analog Resistive Atmel ARM Cortex A5 ATSAMA5D36 512MB LP DDR2 3x RS232 & 1x RS232/422/485 Port, 2x USB 2.0 Host, 1x USB 2.0 OTG SDIO SDHC/ MMC Flash Disk Open Frame PPC7.55" ×4.15" ×1.5" 1x GbE LAN, WiFi 802.11 b/g/n, 16x GPIO lines, I2S Audio
PPC-07-IMX6SPPC-07-IMX6 7" TFT Color WVGA LCD, 800 x 480, 4-Wire Analog Resistive, HDMI, CSI, DSI NXP i.MX6 1.0GHz ARM Solo Processor 512MB Onboard Memory 3x RS232 & 1x RS232/422/485 Port, 2x USB 2.0 Host, 1x USB 2.0 OTG MicroSD, mSATA Socket mini-PCIe Socket with SIM Open Frame PPC7.55" ×4.15" 1x GbE LAN, WiFi 802.11 b/g/n, bluetooth 4.1, 16x GPIO lines
PPC-07-IMX6MPPC-70-IMX6 7" TFT Color WVGA LCD, 800 x 480, 4-Wire Analog Resistive, HDMI, CSI, DSI NXP i.MX6 1.0GHz ARM Dual or Quad Core Processor Up to 2GB DDR3L RAM, 4GB eMMC Flash onboard 3x RS232 & 1x RS232/422/485 Port, 2x USB 2.0 Host, 1x USB 2.0 OTG MicroSD, mSATA Socket mini-PCIe Socket with SIM Open Frame PPC7.55" ×4.15" 1x GbE LAN, WiFi 802.11 b/g/n, bluetooth 4.1, 16x GPIO lines
VOX-070T-EX2PPC-070T-EX2 front 7" WVGA TFT LCD, 800 x 480, resistive touch screen 400 nit or 1000 nit DM&P SoC Vortex86EX2 Master CPU 600MHz (Optional Slave CPU 400MHz) up to 2GB DDR3 onboard 5x COM, 4x USB 2, CAN 4GB onboard eMMC or SD card 4x mini-PCIe sockets 7.323" ×4.764" ×1.13" 1x 10/100 BaseT Ethernet, Audio, 8x GPIO
PPC-080E 8" LCD with Projected Capacitive 10-Point Multitouch Allwinner A40 Cortex™ QuadCore Processor 1GB DDR3 1x serial, 2x USB2, 1x USB OTG 8GB NAND flash, SATA Mini-PCIe expansion Enclosed PPC7.91" ×6.32" ×1.4" Gigabit LAN, POE, Wi-Fi 802.11 b,g,n , HDMI, GPS, Bluetooth
PPC-080T 8" TFT Color LCD, 800 x 600, Analog Resistive Intel Processor N2807 (optional N2600) 2 GB SODIMM DDR3L 3 x RS232*, 1x USB3.0, 3x USB 2.0 SATA SSD Hard Drive 2x Mini PCI-E Enclosed PPC8.5" ×7.2" ×2.2" 2 x GBit RJ45 ports
VOX-084VOX-084 FRONT 8.4" TFT Color WVGA LCD, 800 x 600, 4-Wire Analog Resistive DM&P Vortex86DX2 or Vortex86DX3 800 MHz or 1GHz Up to 2GB DDR3 onboard 4x RS232/422/485, 3x USB2.0 1x SATA PC/104 Open Frame PPC9" ×5.9" ×1.1" 1x 10/100 Ethernet, 2x GbE LAN, 16x GPIO, 1x LPT
PDX-089TPDX-089 Front 8.9" TFT Color LCD, 1024 x 600, Analog Resistive Vortex86DX CPU 512 MB DDR2 on-board 1x RS-232/422/485, 2x USB 2.0 1 IDE, Compact Flash Micro SD Mini PCI Enclosed PPC9.3" ×5.7146" ×1.3" 10/100 Base-T Ethernet, 2x USB 2.0
PMX-089TPMX-089 Front 8.9" TFT Color LCD, 1024 x 600, Analog Resistive Vortex86MX+ Fanless CPU 1GHz Up to 1GB DDR2 onboard 1x RS232/422/485, 2x USB2.0 1 IDE, Compact Flash Micro SD Mini PCI Enclosed PPC9.3" ×5.7" ×1.4" 10/100 Base-T Ethernet
PMX-090TPDX-090T Front 9" TFT Color LCD, 1024 x 600, Analog Resistive Vortex86MX+, 1 GHz Up to 1GB DDR2 onboard 1x RS-232/422/485, 2x USB 2.0 1 IDE, Compact Flash Micro SD Mini PC Enclosed PPC9.31" ×5.75" ×1.38" 10/100 Base-T Ethernet2x USB 2.0
PEX-090TPEX-090T Panel PC 9" VGA TFT LCD Analog Resistive Touch Screen DM&P Vortex 86EX Onboard 400 MHz 1 GB DDR3 Onboard 1x RS-232/422/485 & 2x USB 2.0 MicroSD Slot Enclosed PPC9.31" ×5.75" ×1.38" 1x HD Audio-Realtek ALC262 CODEC, 1x 10/100 Ethernet Integrated, 2x USB 2.0 Ports
PDX2-090TPDX2-090T Panel PC 9" VGA TFT LCD Analog Resistive Touch Screen DM&P Vortex86DX2 933 MHz Up to 2GB DDR2 Onboard 1x RS-232/422/485, 2x USB 2.0 CF Card or Micro SD slot Enclosed PPC9.31" ×5.75" ×1.38" 1x 10/100 Ethernet Integrated, 2x USB 2.0 Ports, HD Audio-Realtek ALC262 CODEC
PDX3-090TPDX3-090T Panel PC 9" VGA TFT LCD Analog Resistive Touch Screen DM&P Vortex86DX3-Fanless Onboard 1GHz Up to 2GB DDR3 Onboard 1x RS-232/422/485, 2x USB 2.0 CF Card & Micro SD slot Enclosed PPC9.31" ×5.75" ×1.38" 1x 10/100 Ethernet Integrated, 2x USB 2.0 Ports, Audio HD Audio-Realtek ALC262 CODEC
PPC-090TPPC-090 Front 9" WSVGA TFT LCD, 1024 x 600 Vortex86DX2, 933 MHz Up to 2GB DDR2 Onboard 2x RS-232 / 422 / 485 SATA Slim DOM Enclosed PPC9.68" ×6.26" ×1.76" Integrated 10/100Mbps Ethernet, Giga Ethernet, Wi-Fi (Optional). 3x USB Ports (Version 2.0) , POE+
PPC-104T 10" TFT Color LCD, 800 x 600, Analog Resistive DM&P Vortex86DX2 933 MHz or Vortex86DX3 1GHZ up to 2 GB DDR3L onboard 2 x RS232/422/485, 3x USB 2.0 Compact Flash or SATA Slim SSD Internal USB Enclosed PPC10.76" ×8.65" ×1.93" 10/100 Mbps LAN (POE optional) / 10/100/1000 GbE (optional), 16x GPIO (optional), up to 7x RS232
PPC-10-IMX6SPPC-10 10" TFT Color WSVGA LCD, 1024 x 600, 4-Wire Analog Resistive, HDMI, CSI, DSI NXP i.MX6 1.0GHz ARM Solo Core Processor 512MB DDR3L, 4GB eMMC Flash onboard 3x RS232 & 1x RS232/422/485 Port, 2x USB 2.0 Host, 1x USB 2.0 OTG MicroSD, mSATA Socket mini-PCIe Socket with SIM 10.5" ×6" ×2" 1x GbE LAN, WiFi 802.11 a/b/g/n, bluetooth, 16x GPIO lines
PPC-10-IMX6MPPC-10 10" TFT Color WSVGA LCD, 1024 x 600, 4-Wire Analog Resistive, HDMI, CSI, DSI NXP i.MX6 1.0GHz ARM Dual or Quad Core Processor Up to 2GB DDR3L, 4GB eMMC Flash onboard 3x RS232 & 1x RS232/422/485 Port, 2x USB 2.0 Host, 1x USB 2.0 OTG MicroSD, mSATA Socket mini-PCIe Socket with SIM Open Frame PPC10.5" ×6" ×2" 1x GbE LAN, WiFi 802.11 a/b/g/n, bluetooth, 16x GPIO lines
PPC-10-3354PPC-10 Panel Open Frame 10" TFT, Color WSVGA LCD, 1024 x 600, 4-Wire Analog Resistive TI ARM Cortex A8 based Processor AM3354, 1.0GHz 512 MB of DDR3 SDRAM, 4GB eMMC Flash 3x RS232 & 1x RS232/422/485 Port, 2x USB 2.0 Host, 1x USB 2.0 OTG SDIO SDHC/ MMC Flash Disk Open Frame PPC5.76" ×10.25" 1x 10/100 BaseT Ethernet, WiFi 802.11 b/g/n, 1x SPI, 1x I2S, Audio Beeper, 1x 12S Audio Port with Line-In/Line-Out, 1x I2C
PPC-10-5D36PPC-10 Panel Open Frame 10" TFT, Color WSVGA LCD, 1024 x 600, 4-Wire Analog Resistive Atmel ARM Cortex A5 ATSAMA5D36 512 MB of DDR2, 4GB eMMC Flash Onboard 3x RS232 & 1x RS232/422/485 Port, 2x USB 2.0 Host, 1x USB 2.0 OTG SDIO SDHC/ MMC Flash Disk Open-Frame5.76" ×10.25" ×1.5" 1x GbE LAN, WiFi 802.11 b/g/n, 1x SPI, 1x I2S, Audio Beeper, 1x 12S Audio Port with Line-In/Line-Out, 1x I2C
UTC-510DUTC-510D 10.1" 1280x800 Projected Capacitive. Glass Panel Intel Bay Trail Atom / Celeron Up to 8GB DDR3L SODIMM 2x COM, 2x USB2, 1x USB3 SATA & mSATA 1x MiniPCIe, 1x mSATA Enclosed PPC10.45" ×7.18" ×1.56" 1x GbE, 1xGbE with POE (optional)
PPC-101E 10.1" LCD with Projected Capacitive 10-Point Multitouch Allwinner A40 Cortex™ QuadCore Processor Up to 2GB DDR3 RAM onboard 1x serial, 2x USB2, 1x USB OTG 8GB NAND flash, SATA Mini-PCIe expansion Enclosed PPC10.87" ×7.56" ×1.34" Gigabit LAN, POE, Wi-Fi 802.11 b,g,n , HDMI, GPS, Bluetooth
VOX-104VOX-104 FRONT 10.4" TFT Color WVGA LCD, 800 x 600, 4-Wire Analog Resistive DM&P Vortex86DX2 or Vortex86DX3 800 MHz or 1GHz Up to 2GB DDR3 onboard 4x RS232/422/485, 3x USB2.0 1x SATA PC/104 Open Frame PPC11.92" ×8.03" ×2.45" 1x 10/100 Ethernet, 2x GbE LAN, 16x GPIO, 1x LPT
PPC-6712 11.6" LED Backlight, WXGA 1366x768, 4-Wire Analog Resistive Touch Intel Celeron J1900 2.42 GHz Up to 8GB DDR3L SODIMM 1x COM, 1x USB 3.0, 2x USB 2.0 header 2.5" SATA, mSATA 1x half-size mini-PCIe &1x full size mini-PCIe x1 slot Enclosed PPC11.25" ×7.25" ×2.5" Dual Gig-Lan, Audio line out, VGA, HDMI,
PPC-3120S 12.1" TFT XGA LED 5 wire- Resistive Touch Screen Intel® Celeron N2930 1.83 GHz up to 8 GB DDR3 SODIMM 2x Serial, 1x USB3, 2x USB2 1x 2.5 Inch SATA HDD Bay (Internal), mSATA 1x MINI PCI-e (Standard), 1x PCI / 1x PCI-e through riser (Optional) Enclosed PPC12.5" ×9.7" ×1.9" 2x GbE, 2x USB 2.0 Ports, Audio, VGA
PPC-IP15PPC-IP15 Front 15'' Color TFT LCD 1024 x 768 Analog resistive, Capacitive, and Infrared Embedded Intel® ULV Celeron® M, 1 GHz Up to 2 GB DDR2 SDRAM 3x RS-232, 1x RS-232/422/485 80GB HD CompactFlash (optional) One each Mini-PCI, PCI, and PCIe Socket Enclosed PPC9.2" ×7.2" ×1.65" 10/100 Base-T Ethernet interface4x USB 2.0 (2 internal, 2 external)
PPC-150T PPC-150T- Panel PC Front View 15" XGA TFT LCD, 1024x768, Analog Resistive or P-Capacitive Vortex86DX2 or Vortex86DX3 933 MHz Up to 2GB DDR2 onboard 2x RS-232/422/485, 2x USB 2.0 Compact Flash or SATA Slim DOM Enclosed PPC13.97" ×8.22" ×2.16" 10/100 LAN, 10/100/1000 Gig LAN (optional), POE(Optional) 3x USB 2 Ports, 5x serial ports optional
VOX-150VOX-150 FRONT 15.0" TFT Color WVGA LCD, 1024 x 768, 4-Wire Analog Resistive DM&P Vortex86DX2 or Vortex86DX3 800 MHz or 1GHz Up to 2GB DDR3 onboard 4x RS232/422/485, 3x USB2.0 1x SATA PC/104 Open Frame PPC14.49" ×10.95" ×2.45" 1x 10/100 Ethernet, 2x GbE LAN, 16x GPIO, 1x LPT
PPC-1581PPC-1581 Panel Front View 15.6 WXGA TFT LED LCD Multi-Touch Projected Capacitive Panel Intel 4th Generation Core i3-4010U 1.7GHz 4GB DDR3L SODIMM 1x RS-232/422/485, 1x RS-232 2.5 Inch SATA SSD Slot, 1x CFast Slot, 1x mSATA (via Mini PCIe slot, can't be used simultaneously with iDoor) 1x Full-size Mini PCI-E Enclosed PPC16.52" ×10.59" ×2.23" 2x Gigabit LAN, 2x USB 3.0, 1x HDMI, Audio Line out, USB 2.0 x 1 (optional) Audio MIC x 1 (optional)
PPC-2155PPC-2155 Front Panel View 15.6” TFT LCD LED Expandable HMI with 5-Wireless Resistive Touch or P-CAP Intel® Celeron® J1900 or N2807 Up to 8GB DDR3L SODIMM 1x RS-232/422/485 1x 2.5 Inch SATA 2.5 HDD Bay, 1x CFast™ 2x Mini card (Full Size), OMNI expansion Enclosed PPC16.5" ×10.4" ×2.4" 2x Gigabit LAN, 1x USB 3.0 Port, 3x USB 2.0 Ports, 2x Mini card (Full Size), 1x Audio Mic-in Line-out, 1x HDMI, 1x VGA
PPC-1154PPC-1154 Panel Front View 15” XGA HMI 5-wire Resistive Touch Panel PC Intel® Celeron® J1900 ,2 GHz / N2807, 1.58 GHz Up to 8GB DDR3L SODIMM 2x RS-485/422/232, 2x RS-232 1x SATA 2.5 Inch HDD Bay / CFast Socket 2x Mini card (Full Size / Half Size) Enclosed PPC16.02" ×12.22" ×2.3" 2x Gigabit LAN, 1x USB 3.0 Port, 3x USB 2.0 Ports, 1x VGA
PPC-2176 PPC-2176-Panel PC Front View 17” TFT LCD Interface with 5-wire Analog Resistive Touch Screen Intel® Celeron® 827E or Core™ i7-2610UE 1.5 GHz Up to 8 GB DDR3 SODIMM 4x RS-232 1x 2.5 Inch SATA Hard Disk Drive/ CFast™ Slot (Internal) 1x PCIe Mini-Card Enclosed PPC16.54" ×14.09" ×3.82" 2x Gigabit LAN, 6x USB 2.0 Ports, 1x VGA, Audio
PPC-215E 21.5" LCD with Projected Capacitive 10-Point Multitouch Allwinner A40 Cortex™ QuadCore Processor up to 2 GB DDR3 1x serial, 2x USB2, 1x USB OTG 8GB NAND flash, SATA Mini-PCIe expansion Enclosed PPC20.79" ×12.76" ×165" Gigabit LAN, POE, Wi-Fi 802.11 b,g,n , HDMI, GPS, Bluetooth
PPC-215T 21.5" LCD with Projected Capacitive 10-Point Multitouch, display port Intel® Celeron™ QuadCore J1900 Up to 4GB DDR3 SODIMM 4x COM, 1x USB 3.0, 3x USB 2.0 ports 64GB SATA SSD 2x Mini-PCIe Enclosed PPC20.79" ×12.76" ×2.28" 2x Gigabit LAN, POE, Wi-Fi 802.11 a,b,g,n , HDMI
PPC-E4+PPC-E4+ Panel PC Front 4.3 " TFT Color WQVGA LCD, 480 x 272, 4-Wire Analog Resistive Embedded Atmel AT91SAM9G45 400 MHz Up to 256 MB DDR2 RAM 3x RS-232, 1x RS-232/422/485, 1x USB Host, 1x USB OTG SDIO, SDHC/ MMC, Flash Disk none Open Frame PPC4.8" ×3" ×1.2" 10/100 Ethernet, Audio, 16x GPIO

Open-Frame PPCs

Product # Video/ Touchscreen CPU Memory Serial Ports Disk Interfaces Bus Dimensions Other I/O
DEV-SOM36PPC-04-5D36 Panel PC Front 4.3 " TFT Color WQVGA LCD, 480 x 272, 4-Wire Analog Resistive Atmel ARM Cortex A5 ATSAMA5D36 512 MB of DDR2 SDRAM, 4GB eMMC Flash Onboard 2x RS-232, 1x RS-232/422/485 with Auto RS485, 2x USB 2.0, CAN, SPI MicroSD None Open Frame PPC4.8" ×3" ×1.2" 10/100 DP83640 IEEE 1588 PTP LAN & GbE Ethernet, Audio, 16x GPIO
PPC-04-3354PPC-04-3554 Panel PC Front 4.3 " TFT Color WQVGA LCD, 480 x 272, 4-Wire Analog Resistive TI ARM Cortex A8 based Processor AM3354, 512 MB of DDR3 SDRAM, 4GB eMMC Flash Onboard 3x RS-232 with handshaking, 1x RS-232/422/485 with Auto RS485, high-speed SPI with chip selects, I2C SDIO SDHC/ MMC Flash Disk None Open Frame PPC4.8" ×3" ×1.2" 10/100 Ethernet, Audio, 16x GPIO
HMI-043T-OPPC-043T 4.3" Open Frame 4.3” WQVGA TFT LCD, 4-wire Analog Resistive Touch Screen DMP Vortex86EXm 400MHz up to 256MB DDR3 onboard 1x RS-232, 2x RS-485, 1xCAN SD Slot or up to 2GB eMMC NAND Flash Memory Onboard Expansion slots Open Frame PPC4.15" ×2.65" ×0.54" Ethernet, 2x USB2.0, 1x 8-bit GPIO
PPC-07-3354PPC-07-3354 Panel Front 7" TFT Color WVGA LCD, 800 x 480, 4-Wire Analog Resistive TI ARM Cortex A8 based Processor AM3354 1.0GHz 512 MB of DDR3 SDRAM, 4GB eMMC Flash Onboard 3x RS232 & 1x RS232/422/485 Port, 2x USB 2.0 Host, 1x USB 2.0 OTG SDIO SDHC/ MMC Flash Disk Open Frame PPC7.55" ×4.15" ×1.5" 1x 10/100 BaseT Ethernet, WiFi 802.11 b/g/n, I2S Audio
PPC-07-5D36PPC-07-A5D3 Panel Front 7" TFT Color WVGA LCD, 800 x 480, 4-Wire Analog Resistive Atmel ARM Cortex A5 ATSAMA5D36 512MB LP DDR2 3x RS232 & 1x RS232/422/485 Port, 2x USB 2.0 Host, 1x USB 2.0 OTG SDIO SDHC/ MMC Flash Disk Open Frame PPC7.55" ×4.15" ×1.5" 1x GbE LAN, WiFi 802.11 b/g/n, 16x GPIO lines, I2S Audio
PPC-07-IMX6SPPC-07-IMX6 7" TFT Color WVGA LCD, 800 x 480, 4-Wire Analog Resistive, HDMI, CSI, DSI NXP i.MX6 1.0GHz ARM Solo Processor 512MB Onboard Memory 3x RS232 & 1x RS232/422/485 Port, 2x USB 2.0 Host, 1x USB 2.0 OTG MicroSD, mSATA Socket mini-PCIe Socket with SIM Open Frame PPC7.55" ×4.15" 1x GbE LAN, WiFi 802.11 b/g/n, bluetooth 4.1, 16x GPIO lines
PPC-07-IMX6MPPC-70-IMX6 7" TFT Color WVGA LCD, 800 x 480, 4-Wire Analog Resistive, HDMI, CSI, DSI NXP i.MX6 1.0GHz ARM Dual or Quad Core Processor Up to 2GB DDR3L RAM, 4GB eMMC Flash onboard 3x RS232 & 1x RS232/422/485 Port, 2x USB 2.0 Host, 1x USB 2.0 OTG MicroSD, mSATA Socket mini-PCIe Socket with SIM Open Frame PPC7.55" ×4.15" 1x GbE LAN, WiFi 802.11 b/g/n, bluetooth 4.1, 16x GPIO lines
VOX-070T-EX2PPC-070T-EX2 front 7" WVGA TFT LCD, 800 x 480, resistive touch screen 400 nit or 1000 nit DM&P SoC Vortex86EX2 Master CPU 600MHz (Optional Slave CPU 400MHz) up to 2GB DDR3 onboard 5x COM, 4x USB 2, CAN 4GB onboard eMMC or SD card 4x mini-PCIe sockets 7.323" ×4.764" ×1.13" 1x 10/100 BaseT Ethernet, Audio, 8x GPIO
VOX-084VOX-084 FRONT 8.4" TFT Color WVGA LCD, 800 x 600, 4-Wire Analog Resistive DM&P Vortex86DX2 or Vortex86DX3 800 MHz or 1GHz Up to 2GB DDR3 onboard 4x RS232/422/485, 3x USB2.0 1x SATA PC/104 Open Frame PPC9" ×5.9" ×1.1" 1x 10/100 Ethernet, 2x GbE LAN, 16x GPIO, 1x LPT
PPC-10-IMX6SPPC-10 10" TFT Color WSVGA LCD, 1024 x 600, 4-Wire Analog Resistive, HDMI, CSI, DSI NXP i.MX6 1.0GHz ARM Solo Core Processor 512MB DDR3L, 4GB eMMC Flash onboard 3x RS232 & 1x RS232/422/485 Port, 2x USB 2.0 Host, 1x USB 2.0 OTG MicroSD, mSATA Socket mini-PCIe Socket with SIM 10.5" ×6" ×2" 1x GbE LAN, WiFi 802.11 a/b/g/n, bluetooth, 16x GPIO lines
PPC-10-IMX6MPPC-10 10" TFT Color WSVGA LCD, 1024 x 600, 4-Wire Analog Resistive, HDMI, CSI, DSI NXP i.MX6 1.0GHz ARM Dual or Quad Core Processor Up to 2GB DDR3L, 4GB eMMC Flash onboard 3x RS232 & 1x RS232/422/485 Port, 2x USB 2.0 Host, 1x USB 2.0 OTG MicroSD, mSATA Socket mini-PCIe Socket with SIM Open Frame PPC10.5" ×6" ×2" 1x GbE LAN, WiFi 802.11 a/b/g/n, bluetooth, 16x GPIO lines
PPC-10-3354PPC-10 Panel Open Frame 10" TFT, Color WSVGA LCD, 1024 x 600, 4-Wire Analog Resistive TI ARM Cortex A8 based Processor AM3354, 1.0GHz 512 MB of DDR3 SDRAM, 4GB eMMC Flash 3x RS232 & 1x RS232/422/485 Port, 2x USB 2.0 Host, 1x USB 2.0 OTG SDIO SDHC/ MMC Flash Disk Open Frame PPC5.76" ×10.25" 1x 10/100 BaseT Ethernet, WiFi 802.11 b/g/n, 1x SPI, 1x I2S, Audio Beeper, 1x 12S Audio Port with Line-In/Line-Out, 1x I2C
PPC-10-5D36PPC-10 Panel Open Frame 10" TFT, Color WSVGA LCD, 1024 x 600, 4-Wire Analog Resistive Atmel ARM Cortex A5 ATSAMA5D36 512 MB of DDR2, 4GB eMMC Flash Onboard 3x RS232 & 1x RS232/422/485 Port, 2x USB 2.0 Host, 1x USB 2.0 OTG SDIO SDHC/ MMC Flash Disk Open-Frame5.76" ×10.25" ×1.5" 1x GbE LAN, WiFi 802.11 b/g/n, 1x SPI, 1x I2S, Audio Beeper, 1x 12S Audio Port with Line-In/Line-Out, 1x I2C
VOX-104VOX-104 FRONT 10.4" TFT Color WVGA LCD, 800 x 600, 4-Wire Analog Resistive DM&P Vortex86DX2 or Vortex86DX3 800 MHz or 1GHz Up to 2GB DDR3 onboard 4x RS232/422/485, 3x USB2.0 1x SATA PC/104 Open Frame PPC11.92" ×8.03" ×2.45" 1x 10/100 Ethernet, 2x GbE LAN, 16x GPIO, 1x LPT
VOX-150VOX-150 FRONT 15.0" TFT Color WVGA LCD, 1024 x 768, 4-Wire Analog Resistive DM&P Vortex86DX2 or Vortex86DX3 800 MHz or 1GHz Up to 2GB DDR3 onboard 4x RS232/422/485, 3x USB2.0 1x SATA PC/104 Open Frame PPC14.49" ×10.95" ×2.45" 1x 10/100 Ethernet, 2x GbE LAN, 16x GPIO, 1x LPT
PPC-E4+PPC-E4+ Panel PC Front 4.3 " TFT Color WQVGA LCD, 480 x 272, 4-Wire Analog Resistive Embedded Atmel AT91SAM9G45 400 MHz Up to 256 MB DDR2 RAM 3x RS-232, 1x RS-232/422/485, 1x USB Host, 1x USB OTG SDIO, SDHC/ MMC, Flash Disk none Open Frame PPC4.8" ×3" ×1.2" 10/100 Ethernet, Audio, 16x GPIO

Enclosed PPCs

Product # Video/ Touchscreen CPU Memory Serial Ports Disk Interfaces Bus Dims. Other I/O
HMI-043THMI-043T x86 Panel PC 4.3 " TFT, Color WQVGA LCD, 480 x 272, 4-Wire Analog Resistive DMP Vortex86EXm 400 MHz Up to 256 MB DDR3 RAM Onboard 1x RS-232, 485 or CAN SD Slot or up to 2GB eMMC NAND Flash Memory Onboard N/A 4.58" ×3.71" ×1.35" Ethernet, POE, HF RFID/NFC, 1x USB 2.0
PDX-057TPDX-057 Panel PC 5.7" TFT Color LCD, 640 x 480, Analog Resistive Vortex86DX Fanless CPU, 1 GHz Up to 512MB RAM 1x RS-232/422/485, 2x USB 2.0 1 IDE, Compact Flash Micro SD Mini PCI 6" ×4.4" ×1.2" RDC 6040 10/100 Base-T Ethernet2x USB 2.0
PMX-057TPMX-057 5.7" TFT Color LCD, 640 x 480, Analog Resistive Vortex86MX+ Fanless CPU 1GHz Up to 1GB DDR2 onboard 1x RS-232/422/485, 2x USB 2.0 1x RS232/422/485 1 IDE, Compact Flash Micro SD Mini PCI 6" ×4.4" ×1.2" 10/100 Base-T Ethernet, 2x USB 2.0, Audio
PDX2-057TPDX2-057T Enclosed Panel PC 5.7" TFT LCD with Resistive Touch Screen DM&P Vortex86DX2 - 933MHz Up to 2GB DDR2 Onboard 1x RS-232/422/485, 2x USB 2.0 CF Card or Micro SD slot 5.98" ×4.41" ×1.3" 1x HD Audio-Realtek ALC262 CODEC, 1x 10/100 Ethernet Integrated, 2x USB 2.0 Ports
PEX-057TPEX-057T Panel PC 5.7" VGA TFT LCD with Resistive Touch Screen DM&P Vortex 86EX Onboard 400 MHz 1 GB DDR3 Onboard 1x RS-232/422/485 & 2x USB 2.0 MicroSD Slot 5.98" ×4.41" ×1.3" 1x HD Audio-Realtek ALC262 CODEC, 1x 10/100 Ethernet Integrated, 2x USB 2.0 Ports
PDX3-057TPDX3-057T Panel PC 5.7" VGA TFT LCD with Resistive Touch Screen DM&P Vortex86DX3-Fanless Onboard 1GHz Up to 2GB DDR3 Onboard 1x RS-232/422/485, 2x USB 2.0 CF Card or Micro SD slot 5.98" ×4.41" ×1.3" 1x 10/100 Ethernet Integrated, 2x USB 2.0 Ports, Audio HD Audio-Realtek ALC262 CODEC
PPC-080E 8" LCD with Projected Capacitive 10-Point Multitouch Allwinner A40 Cortex™ QuadCore Processor 1GB DDR3 1x serial, 2x USB2, 1x USB OTG 8GB NAND flash, SATA Mini-PCIe expansion 7.91" ×6.32" ×1.4" Gigabit LAN, POE, Wi-Fi 802.11 b,g,n , HDMI, GPS, Bluetooth
PPC-080T 8" TFT Color LCD, 800 x 600, Analog Resistive Intel Processor N2807 (optional N2600) 2 GB SODIMM DDR3L 3 x RS232*, 1x USB3.0, 3x USB 2.0 SATA SSD Hard Drive 2x Mini PCI-E 8.5" ×7.2" ×2.2" 2 x GBit RJ45 ports
PDX-089TPDX-089 Front 8.9" TFT Color LCD, 1024 x 600, Analog Resistive Vortex86DX CPU 512 MB DDR2 on-board 1x RS-232/422/485, 2x USB 2.0 1 IDE, Compact Flash Micro SD Mini PCI 9.3" ×5.7146" ×1.3" 10/100 Base-T Ethernet, 2x USB 2.0
PMX-089TPMX-089 Front 8.9" TFT Color LCD, 1024 x 600, Analog Resistive Vortex86MX+ Fanless CPU 1GHz Up to 1GB DDR2 onboard 1x RS232/422/485, 2x USB2.0 1 IDE, Compact Flash Micro SD Mini PCI 9.3" ×5.7" ×1.4" 10/100 Base-T Ethernet
PMX-090TPDX-090T Front 9" TFT Color LCD, 1024 x 600, Analog Resistive Vortex86MX+, 1 GHz Up to 1GB DDR2 onboard 1x RS-232/422/485, 2x USB 2.0 1 IDE, Compact Flash Micro SD Mini PC 9.31" ×5.75" ×1.38" 10/100 Base-T Ethernet2x USB 2.0
PEX-090TPEX-090T Panel PC 9" VGA TFT LCD Analog Resistive Touch Screen DM&P Vortex 86EX Onboard 400 MHz 1 GB DDR3 Onboard 1x RS-232/422/485 & 2x USB 2.0 MicroSD Slot 9.31" ×5.75" ×1.38" 1x HD Audio-Realtek ALC262 CODEC, 1x 10/100 Ethernet Integrated, 2x USB 2.0 Ports
PDX2-090TPDX2-090T Panel PC 9" VGA TFT LCD Analog Resistive Touch Screen DM&P Vortex86DX2 933 MHz Up to 2GB DDR2 Onboard 1x RS-232/422/485, 2x USB 2.0 CF Card or Micro SD slot 9.31" ×5.75" ×1.38" 1x 10/100 Ethernet Integrated, 2x USB 2.0 Ports, HD Audio-Realtek ALC262 CODEC
PDX3-090TPDX3-090T Panel PC 9" VGA TFT LCD Analog Resistive Touch Screen DM&P Vortex86DX3-Fanless Onboard 1GHz Up to 2GB DDR3 Onboard 1x RS-232/422/485, 2x USB 2.0 CF Card & Micro SD slot 9.31" ×5.75" ×1.38" 1x 10/100 Ethernet Integrated, 2x USB 2.0 Ports, Audio HD Audio-Realtek ALC262 CODEC
PPC-090TPPC-090 Front 9" WSVGA TFT LCD, 1024 x 600 Vortex86DX2, 933 MHz Up to 2GB DDR2 Onboard 2x RS-232 / 422 / 485 SATA Slim DOM 9.68" ×6.26" ×1.76" Integrated 10/100Mbps Ethernet, Giga Ethernet, Wi-Fi (Optional). 3x USB Ports (Version 2.0) , POE+
PPC-104T 10" TFT Color LCD, 800 x 600, Analog Resistive DM&P Vortex86DX2 933 MHz or Vortex86DX3 1GHZ up to 2 GB DDR3L onboard 2 x RS232/422/485, 3x USB 2.0 Compact Flash or SATA Slim SSD Internal USB 10.76" ×8.65" ×1.93" 10/100 Mbps LAN (POE optional) / 10/100/1000 GbE (optional), 16x GPIO (optional), up to 7x RS232
UTC-510DUTC-510D 10.1" 1280x800 Projected Capacitive. Glass Panel Intel Bay Trail Atom / Celeron Up to 8GB DDR3L SODIMM 2x COM, 2x USB2, 1x USB3 SATA & mSATA 1x MiniPCIe, 1x mSATA 10.45" ×7.18" ×1.56" 1x GbE, 1xGbE with POE (optional)
PPC-101E 10.1" LCD with Projected Capacitive 10-Point Multitouch Allwinner A40 Cortex™ QuadCore Processor Up to 2GB DDR3 RAM onboard 1x serial, 2x USB2, 1x USB OTG 8GB NAND flash, SATA Mini-PCIe expansion 10.87" ×7.56" ×1.34" Gigabit LAN, POE, Wi-Fi 802.11 b,g,n , HDMI, GPS, Bluetooth
PPC-6712 11.6" LED Backlight, WXGA 1366x768, 4-Wire Analog Resistive Touch Intel Celeron J1900 2.42 GHz Up to 8GB DDR3L SODIMM 1x COM, 1x USB 3.0, 2x USB 2.0 header 2.5" SATA, mSATA 1x half-size mini-PCIe &1x full size mini-PCIe x1 slot 11.25" ×7.25" ×2.5" Dual Gig-Lan, Audio line out, VGA, HDMI,
PPC-3120S 12.1" TFT XGA LED 5 wire- Resistive Touch Screen Intel® Celeron N2930 1.83 GHz up to 8 GB DDR3 SODIMM 2x Serial, 1x USB3, 2x USB2 1x 2.5 Inch SATA HDD Bay (Internal), mSATA 1x MINI PCI-e (Standard), 1x PCI / 1x PCI-e through riser (Optional) 12.5" ×9.7" ×1.9" 2x GbE, 2x USB 2.0 Ports, Audio, VGA
PPC-IP15PPC-IP15 Front 15'' Color TFT LCD 1024 x 768 Analog resistive, Capacitive, and Infrared Embedded Intel® ULV Celeron® M, 1 GHz Up to 2 GB DDR2 SDRAM 3x RS-232, 1x RS-232/422/485 80GB HD CompactFlash (optional) One each Mini-PCI, PCI, and PCIe Socket 9.2" ×7.2" ×1.65" 10/100 Base-T Ethernet interface4x USB 2.0 (2 internal, 2 external)
PPC-150T PPC-150T- Panel PC Front View 15" XGA TFT LCD, 1024x768, Analog Resistive or P-Capacitive Vortex86DX2 or Vortex86DX3 933 MHz Up to 2GB DDR2 onboard 2x RS-232/422/485, 2x USB 2.0 Compact Flash or SATA Slim DOM 13.97" ×8.22" ×2.16" 10/100 LAN, 10/100/1000 Gig LAN (optional), POE(Optional) 3x USB 2 Ports, 5x serial ports optional
PPC-1581PPC-1581 Panel Front View 15.6 WXGA TFT LED LCD Multi-Touch Projected Capacitive Panel Intel 4th Generation Core i3-4010U 1.7GHz 4GB DDR3L SODIMM 1x RS-232/422/485, 1x RS-232 2.5 Inch SATA SSD Slot, 1x CFast Slot, 1x mSATA (via Mini PCIe slot, can't be used simultaneously with iDoor) 1x Full-size Mini PCI-E 16.52" ×10.59" ×2.23" 2x Gigabit LAN, 2x USB 3.0, 1x HDMI, Audio Line out, USB 2.0 x 1 (optional) Audio MIC x 1 (optional)
PPC-2155PPC-2155 Front Panel View 15.6” TFT LCD LED Expandable HMI with 5-Wireless Resistive Touch or P-CAP Intel® Celeron® J1900 or N2807 Up to 8GB DDR3L SODIMM 1x RS-232/422/485 1x 2.5 Inch SATA 2.5 HDD Bay, 1x CFast™ 2x Mini card (Full Size), OMNI expansion 16.5" ×10.4" ×2.4" 2x Gigabit LAN, 1x USB 3.0 Port, 3x USB 2.0 Ports, 2x Mini card (Full Size), 1x Audio Mic-in Line-out, 1x HDMI, 1x VGA
PPC-1154PPC-1154 Panel Front View 15” XGA HMI 5-wire Resistive Touch Panel PC Intel® Celeron® J1900 ,2 GHz / N2807, 1.58 GHz Up to 8GB DDR3L SODIMM 2x RS-485/422/232, 2x RS-232 1x SATA 2.5 Inch HDD Bay / CFast Socket 2x Mini card (Full Size / Half Size) 16.02" ×12.22" ×2.3" 2x Gigabit LAN, 1x USB 3.0 Port, 3x USB 2.0 Ports, 1x VGA
PPC-2176 PPC-2176-Panel PC Front View 17” TFT LCD Interface with 5-wire Analog Resistive Touch Screen Intel® Celeron® 827E or Core™ i7-2610UE 1.5 GHz Up to 8 GB DDR3 SODIMM 4x RS-232 1x 2.5 Inch SATA Hard Disk Drive/ CFast™ Slot (Internal) 1x PCIe Mini-Card 16.54" ×14.09" ×3.82" 2x Gigabit LAN, 6x USB 2.0 Ports, 1x VGA, Audio
PPC-215E 21.5" LCD with Projected Capacitive 10-Point Multitouch Allwinner A40 Cortex™ QuadCore Processor up to 2 GB DDR3 1x serial, 2x USB2, 1x USB OTG 8GB NAND flash, SATA Mini-PCIe expansion 20.79" ×12.76" ×165" Gigabit LAN, POE, Wi-Fi 802.11 b,g,n , HDMI, GPS, Bluetooth
PPC-215T 21.5" LCD with Projected Capacitive 10-Point Multitouch, display port Intel® Celeron™ QuadCore J1900 Up to 4GB DDR3 SODIMM 4x COM, 1x USB 3.0, 3x USB 2.0 ports 64GB SATA SSD 2x Mini-PCIe 20.79" ×12.76" ×2.28" 2x Gigabit LAN, POE, Wi-Fi 802.11 a,b,g,n , HDMI

PPCs > 12 in

Product # Video/ Touchscreen CPU Memory Serial Ports Disk Interfaces Bus Dimensions Other I/O
DEV-SOM36PPC-04-5D36 Panel PC Front 4.3 " TFT Color WQVGA LCD, 480 x 272, 4-Wire Analog Resistive Atmel ARM Cortex A5 ATSAMA5D36 512 MB of DDR2 SDRAM, 4GB eMMC Flash Onboard 2x RS-232, 1x RS-232/422/485 with Auto RS485, 2x USB 2.0, CAN, SPI MicroSD None Open Frame PPC4.8" ×3" ×1.2" 10/100 DP83640 IEEE 1588 PTP LAN & GbE Ethernet, Audio, 16x GPIO
VOX-070T-EX2PPC-070T-EX2 front 7" WVGA TFT LCD, 800 x 480, resistive touch screen 400 nit or 1000 nit DM&P SoC Vortex86EX2 Master CPU 600MHz (Optional Slave CPU 400MHz) up to 2GB DDR3 onboard 5x COM, 4x USB 2, CAN 4GB onboard eMMC or SD card 4x mini-PCIe sockets 7.323" ×4.764" ×1.13" 1x 10/100 BaseT Ethernet, Audio, 8x GPIO
PPC-3120S 12.1" TFT XGA LED 5 wire- Resistive Touch Screen Intel® Celeron N2930 1.83 GHz up to 8 GB DDR3 SODIMM 2x Serial, 1x USB3, 2x USB2 1x 2.5 Inch SATA HDD Bay (Internal), mSATA 1x MINI PCI-e (Standard), 1x PCI / 1x PCI-e through riser (Optional) Enclosed PPC12.5" ×9.7" ×1.9" 2x GbE, 2x USB 2.0 Ports, Audio, VGA
PPC-IP15PPC-IP15 Front 15'' Color TFT LCD 1024 x 768 Analog resistive, Capacitive, and Infrared Embedded Intel® ULV Celeron® M, 1 GHz Up to 2 GB DDR2 SDRAM 3x RS-232, 1x RS-232/422/485 80GB HD CompactFlash (optional) One each Mini-PCI, PCI, and PCIe Socket Enclosed PPC9.2" ×7.2" ×1.65" 10/100 Base-T Ethernet interface4x USB 2.0 (2 internal, 2 external)
PPC-150T PPC-150T- Panel PC Front View 15" XGA TFT LCD, 1024x768, Analog Resistive or P-Capacitive Vortex86DX2 or Vortex86DX3 933 MHz Up to 2GB DDR2 onboard 2x RS-232/422/485, 2x USB 2.0 Compact Flash or SATA Slim DOM Enclosed PPC13.97" ×8.22" ×2.16" 10/100 LAN, 10/100/1000 Gig LAN (optional), POE(Optional) 3x USB 2 Ports, 5x serial ports optional
VOX-150VOX-150 FRONT 15.0" TFT Color WVGA LCD, 1024 x 768, 4-Wire Analog Resistive DM&P Vortex86DX2 or Vortex86DX3 800 MHz or 1GHz Up to 2GB DDR3 onboard 4x RS232/422/485, 3x USB2.0 1x SATA PC/104 Open Frame PPC14.49" ×10.95" ×2.45" 1x 10/100 Ethernet, 2x GbE LAN, 16x GPIO, 1x LPT
PPC-1581PPC-1581 Panel Front View 15.6 WXGA TFT LED LCD Multi-Touch Projected Capacitive Panel Intel 4th Generation Core i3-4010U 1.7GHz 4GB DDR3L SODIMM 1x RS-232/422/485, 1x RS-232 2.5 Inch SATA SSD Slot, 1x CFast Slot, 1x mSATA (via Mini PCIe slot, can't be used simultaneously with iDoor) 1x Full-size Mini PCI-E Enclosed PPC16.52" ×10.59" ×2.23" 2x Gigabit LAN, 2x USB 3.0, 1x HDMI, Audio Line out, USB 2.0 x 1 (optional) Audio MIC x 1 (optional)
PPC-2155PPC-2155 Front Panel View 15.6” TFT LCD LED Expandable HMI with 5-Wireless Resistive Touch or P-CAP Intel® Celeron® J1900 or N2807 Up to 8GB DDR3L SODIMM 1x RS-232/422/485 1x 2.5 Inch SATA 2.5 HDD Bay, 1x CFast™ 2x Mini card (Full Size), OMNI expansion Enclosed PPC16.5" ×10.4" ×2.4" 2x Gigabit LAN, 1x USB 3.0 Port, 3x USB 2.0 Ports, 2x Mini card (Full Size), 1x Audio Mic-in Line-out, 1x HDMI, 1x VGA
PPC-1154PPC-1154 Panel Front View 15” XGA HMI 5-wire Resistive Touch Panel PC Intel® Celeron® J1900 ,2 GHz / N2807, 1.58 GHz Up to 8GB DDR3L SODIMM 2x RS-485/422/232, 2x RS-232 1x SATA 2.5 Inch HDD Bay / CFast Socket 2x Mini card (Full Size / Half Size) Enclosed PPC16.02" ×12.22" ×2.3" 2x Gigabit LAN, 1x USB 3.0 Port, 3x USB 2.0 Ports, 1x VGA
PPC-2176 PPC-2176-Panel PC Front View 17” TFT LCD Interface with 5-wire Analog Resistive Touch Screen Intel® Celeron® 827E or Core™ i7-2610UE 1.5 GHz Up to 8 GB DDR3 SODIMM 4x RS-232 1x 2.5 Inch SATA Hard Disk Drive/ CFast™ Slot (Internal) 1x PCIe Mini-Card Enclosed PPC16.54" ×14.09" ×3.82" 2x Gigabit LAN, 6x USB 2.0 Ports, 1x VGA, Audio
PPC-215E 21.5" LCD with Projected Capacitive 10-Point Multitouch Allwinner A40 Cortex™ QuadCore Processor up to 2 GB DDR3 1x serial, 2x USB2, 1x USB OTG 8GB NAND flash, SATA Mini-PCIe expansion Enclosed PPC20.79" ×12.76" ×165" Gigabit LAN, POE, Wi-Fi 802.11 b,g,n , HDMI, GPS, Bluetooth
PPC-215T 21.5" LCD with Projected Capacitive 10-Point Multitouch, display port Intel® Celeron™ QuadCore J1900 Up to 4GB DDR3 SODIMM 4x COM, 1x USB 3.0, 3x USB 2.0 ports 64GB SATA SSD 2x Mini-PCIe Enclosed PPC20.79" ×12.76" ×2.28" 2x Gigabit LAN, POE, Wi-Fi 802.11 a,b,g,n , HDMI

PPCs < 12 in

Product # Video/ Touchscreen CPU Memory Serial Ports Disk Interfaces Bus Dimensions Other I/O
PPC-04-3354PPC-04-3554 Panel PC Front 4.3 " TFT Color WQVGA LCD, 480 x 272, 4-Wire Analog Resistive TI ARM Cortex A8 based Processor AM3354, 512 MB of DDR3 SDRAM, 4GB eMMC Flash Onboard 3x RS-232 with handshaking, 1x RS-232/422/485 with Auto RS485, high-speed SPI with chip selects, I2C SDIO SDHC/ MMC Flash Disk None Open Frame PPC4.8" ×3" ×1.2" 10/100 Ethernet, Audio, 16x GPIO
HMI-043THMI-043T x86 Panel PC 4.3 " TFT, Color WQVGA LCD, 480 x 272, 4-Wire Analog Resistive DMP Vortex86EXm 400 MHz Up to 256 MB DDR3 RAM Onboard 1x RS-232, 485 or CAN SD Slot or up to 2GB eMMC NAND Flash Memory Onboard N/A Enclosed PPC4.58" ×3.71" ×1.35" Ethernet, POE, HF RFID/NFC, 1x USB 2.0
HMI-043T-OPPC-043T 4.3" Open Frame 4.3” WQVGA TFT LCD, 4-wire Analog Resistive Touch Screen DMP Vortex86EXm 400MHz up to 256MB DDR3 onboard 1x RS-232, 2x RS-485, 1xCAN SD Slot or up to 2GB eMMC NAND Flash Memory Onboard Expansion slots Open Frame PPC4.15" ×2.65" ×0.54" Ethernet, 2x USB2.0, 1x 8-bit GPIO
PDX-057TPDX-057 Panel PC 5.7" TFT Color LCD, 640 x 480, Analog Resistive Vortex86DX Fanless CPU, 1 GHz Up to 512MB RAM 1x RS-232/422/485, 2x USB 2.0 1 IDE, Compact Flash Micro SD Mini PCI Enclosed PPC6" ×4.4" ×1.2" RDC 6040 10/100 Base-T Ethernet2x USB 2.0
PMX-057TPMX-057 5.7" TFT Color LCD, 640 x 480, Analog Resistive Vortex86MX+ Fanless CPU 1GHz Up to 1GB DDR2 onboard 1x RS-232/422/485, 2x USB 2.0 1x RS232/422/485 1 IDE, Compact Flash Micro SD Mini PCI Enclosed PPC6" ×4.4" ×1.2" 10/100 Base-T Ethernet, 2x USB 2.0, Audio
PDX2-057TPDX2-057T Enclosed Panel PC 5.7" TFT LCD with Resistive Touch Screen DM&P Vortex86DX2 - 933MHz Up to 2GB DDR2 Onboard 1x RS-232/422/485, 2x USB 2.0 CF Card or Micro SD slot Enclosed PPC5.98" ×4.41" ×1.3" 1x HD Audio-Realtek ALC262 CODEC, 1x 10/100 Ethernet Integrated, 2x USB 2.0 Ports
PEX-057TPEX-057T Panel PC 5.7" VGA TFT LCD with Resistive Touch Screen DM&P Vortex 86EX Onboard 400 MHz 1 GB DDR3 Onboard 1x RS-232/422/485 & 2x USB 2.0 MicroSD Slot Enclosed PPC5.98" ×4.41" ×1.3" 1x HD Audio-Realtek ALC262 CODEC, 1x 10/100 Ethernet Integrated, 2x USB 2.0 Ports
PDX3-057TPDX3-057T Panel PC 5.7" VGA TFT LCD with Resistive Touch Screen DM&P Vortex86DX3-Fanless Onboard 1GHz Up to 2GB DDR3 Onboard 1x RS-232/422/485, 2x USB 2.0 CF Card or Micro SD slot Enclosed PPC5.98" ×4.41" ×1.3" 1x 10/100 Ethernet Integrated, 2x USB 2.0 Ports, Audio HD Audio-Realtek ALC262 CODEC
PPC-07-3354PPC-07-3354 Panel Front 7" TFT Color WVGA LCD, 800 x 480, 4-Wire Analog Resistive TI ARM Cortex A8 based Processor AM3354 1.0GHz 512 MB of DDR3 SDRAM, 4GB eMMC Flash Onboard 3x RS232 & 1x RS232/422/485 Port, 2x USB 2.0 Host, 1x USB 2.0 OTG SDIO SDHC/ MMC Flash Disk Open Frame PPC7.55" ×4.15" ×1.5" 1x 10/100 BaseT Ethernet, WiFi 802.11 b/g/n, I2S Audio
PPC-07-5D36PPC-07-A5D3 Panel Front 7" TFT Color WVGA LCD, 800 x 480, 4-Wire Analog Resistive Atmel ARM Cortex A5 ATSAMA5D36 512MB LP DDR2 3x RS232 & 1x RS232/422/485 Port, 2x USB 2.0 Host, 1x USB 2.0 OTG SDIO SDHC/ MMC Flash Disk Open Frame PPC7.55" ×4.15" ×1.5" 1x GbE LAN, WiFi 802.11 b/g/n, 16x GPIO lines, I2S Audio
PPC-07-IMX6SPPC-07-IMX6 7" TFT Color WVGA LCD, 800 x 480, 4-Wire Analog Resistive, HDMI, CSI, DSI NXP i.MX6 1.0GHz ARM Solo Processor 512MB Onboard Memory 3x RS232 & 1x RS232/422/485 Port, 2x USB 2.0 Host, 1x USB 2.0 OTG MicroSD, mSATA Socket mini-PCIe Socket with SIM Open Frame PPC7.55" ×4.15" 1x GbE LAN, WiFi 802.11 b/g/n, bluetooth 4.1, 16x GPIO lines
PPC-07-IMX6MPPC-70-IMX6 7" TFT Color WVGA LCD, 800 x 480, 4-Wire Analog Resistive, HDMI, CSI, DSI NXP i.MX6 1.0GHz ARM Dual or Quad Core Processor Up to 2GB DDR3L RAM, 4GB eMMC Flash onboard 3x RS232 & 1x RS232/422/485 Port, 2x USB 2.0 Host, 1x USB 2.0 OTG MicroSD, mSATA Socket mini-PCIe Socket with SIM Open Frame PPC7.55" ×4.15" 1x GbE LAN, WiFi 802.11 b/g/n, bluetooth 4.1, 16x GPIO lines
PPC-080E 8" LCD with Projected Capacitive 10-Point Multitouch Allwinner A40 Cortex™ QuadCore Processor 1GB DDR3 1x serial, 2x USB2, 1x USB OTG 8GB NAND flash, SATA Mini-PCIe expansion Enclosed PPC7.91" ×6.32" ×1.4" Gigabit LAN, POE, Wi-Fi 802.11 b,g,n , HDMI, GPS, Bluetooth
PPC-080T 8" TFT Color LCD, 800 x 600, Analog Resistive Intel Processor N2807 (optional N2600) 2 GB SODIMM DDR3L 3 x RS232*, 1x USB3.0, 3x USB 2.0 SATA SSD Hard Drive 2x Mini PCI-E Enclosed PPC8.5" ×7.2" ×2.2" 2 x GBit RJ45 ports
VOX-084VOX-084 FRONT 8.4" TFT Color WVGA LCD, 800 x 600, 4-Wire Analog Resistive DM&P Vortex86DX2 or Vortex86DX3 800 MHz or 1GHz Up to 2GB DDR3 onboard 4x RS232/422/485, 3x USB2.0 1x SATA PC/104 Open Frame PPC9" ×5.9" ×1.1" 1x 10/100 Ethernet, 2x GbE LAN, 16x GPIO, 1x LPT
PDX-089TPDX-089 Front 8.9" TFT Color LCD, 1024 x 600, Analog Resistive Vortex86DX CPU 512 MB DDR2 on-board 1x RS-232/422/485, 2x USB 2.0 1 IDE, Compact Flash Micro SD Mini PCI Enclosed PPC9.3" ×5.7146" ×1.3" 10/100 Base-T Ethernet, 2x USB 2.0
PMX-089TPMX-089 Front 8.9" TFT Color LCD, 1024 x 600, Analog Resistive Vortex86MX+ Fanless CPU 1GHz Up to 1GB DDR2 onboard 1x RS232/422/485, 2x USB2.0 1 IDE, Compact Flash Micro SD Mini PCI Enclosed PPC9.3" ×5.7" ×1.4" 10/100 Base-T Ethernet
PMX-090TPDX-090T Front 9" TFT Color LCD, 1024 x 600, Analog Resistive Vortex86MX+, 1 GHz Up to 1GB DDR2 onboard 1x RS-232/422/485, 2x USB 2.0 1 IDE, Compact Flash Micro SD Mini PC Enclosed PPC9.31" ×5.75" ×1.38" 10/100 Base-T Ethernet2x USB 2.0
PEX-090TPEX-090T Panel PC 9" VGA TFT LCD Analog Resistive Touch Screen DM&P Vortex 86EX Onboard 400 MHz 1 GB DDR3 Onboard 1x RS-232/422/485 & 2x USB 2.0 MicroSD Slot Enclosed PPC9.31" ×5.75" ×1.38" 1x HD Audio-Realtek ALC262 CODEC, 1x 10/100 Ethernet Integrated, 2x USB 2.0 Ports
PDX2-090TPDX2-090T Panel PC 9" VGA TFT LCD Analog Resistive Touch Screen DM&P Vortex86DX2 933 MHz Up to 2GB DDR2 Onboard 1x RS-232/422/485, 2x USB 2.0 CF Card or Micro SD slot Enclosed PPC9.31" ×5.75" ×1.38" 1x 10/100 Ethernet Integrated, 2x USB 2.0 Ports, HD Audio-Realtek ALC262 CODEC
PDX3-090TPDX3-090T Panel PC 9" VGA TFT LCD Analog Resistive Touch Screen DM&P Vortex86DX3-Fanless Onboard 1GHz Up to 2GB DDR3 Onboard 1x RS-232/422/485, 2x USB 2.0 CF Card & Micro SD slot Enclosed PPC9.31" ×5.75" ×1.38" 1x 10/100 Ethernet Integrated, 2x USB 2.0 Ports, Audio HD Audio-Realtek ALC262 CODEC
PPC-090TPPC-090 Front 9" WSVGA TFT LCD, 1024 x 600 Vortex86DX2, 933 MHz Up to 2GB DDR2 Onboard 2x RS-232 / 422 / 485 SATA Slim DOM Enclosed PPC9.68" ×6.26" ×1.76" Integrated 10/100Mbps Ethernet, Giga Ethernet, Wi-Fi (Optional). 3x USB Ports (Version 2.0) , POE+
PPC-104T 10" TFT Color LCD, 800 x 600, Analog Resistive DM&P Vortex86DX2 933 MHz or Vortex86DX3 1GHZ up to 2 GB DDR3L onboard 2 x RS232/422/485, 3x USB 2.0 Compact Flash or SATA Slim SSD Internal USB Enclosed PPC10.76" ×8.65" ×1.93" 10/100 Mbps LAN (POE optional) / 10/100/1000 GbE (optional), 16x GPIO (optional), up to 7x RS232
PPC-10-IMX6SPPC-10 10" TFT Color WSVGA LCD, 1024 x 600, 4-Wire Analog Resistive, HDMI, CSI, DSI NXP i.MX6 1.0GHz ARM Solo Core Processor 512MB DDR3L, 4GB eMMC Flash onboard 3x RS232 & 1x RS232/422/485 Port, 2x USB 2.0 Host, 1x USB 2.0 OTG MicroSD, mSATA Socket mini-PCIe Socket with SIM 10.5" ×6" ×2" 1x GbE LAN, WiFi 802.11 a/b/g/n, bluetooth, 16x GPIO lines
PPC-10-IMX6MPPC-10 10" TFT Color WSVGA LCD, 1024 x 600, 4-Wire Analog Resistive, HDMI, CSI, DSI NXP i.MX6 1.0GHz ARM Dual or Quad Core Processor Up to 2GB DDR3L, 4GB eMMC Flash onboard 3x RS232 & 1x RS232/422/485 Port, 2x USB 2.0 Host, 1x USB 2.0 OTG MicroSD, mSATA Socket mini-PCIe Socket with SIM Open Frame PPC10.5" ×6" ×2" 1x GbE LAN, WiFi 802.11 a/b/g/n, bluetooth, 16x GPIO lines
PPC-10-3354PPC-10 Panel Open Frame 10" TFT, Color WSVGA LCD, 1024 x 600, 4-Wire Analog Resistive TI ARM Cortex A8 based Processor AM3354, 1.0GHz 512 MB of DDR3 SDRAM, 4GB eMMC Flash 3x RS232 & 1x RS232/422/485 Port, 2x USB 2.0 Host, 1x USB 2.0 OTG SDIO SDHC/ MMC Flash Disk Open Frame PPC5.76" ×10.25" 1x 10/100 BaseT Ethernet, WiFi 802.11 b/g/n, 1x SPI, 1x I2S, Audio Beeper, 1x 12S Audio Port with Line-In/Line-Out, 1x I2C
PPC-10-5D36PPC-10 Panel Open Frame 10" TFT, Color WSVGA LCD, 1024 x 600, 4-Wire Analog Resistive Atmel ARM Cortex A5 ATSAMA5D36 512 MB of DDR2, 4GB eMMC Flash Onboard 3x RS232 & 1x RS232/422/485 Port, 2x USB 2.0 Host, 1x USB 2.0 OTG SDIO SDHC/ MMC Flash Disk Open-Frame5.76" ×10.25" ×1.5" 1x GbE LAN, WiFi 802.11 b/g/n, 1x SPI, 1x I2S, Audio Beeper, 1x 12S Audio Port with Line-In/Line-Out, 1x I2C
UTC-510DUTC-510D 10.1" 1280x800 Projected Capacitive. Glass Panel Intel Bay Trail Atom / Celeron Up to 8GB DDR3L SODIMM 2x COM, 2x USB2, 1x USB3 SATA & mSATA 1x MiniPCIe, 1x mSATA Enclosed PPC10.45" ×7.18" ×1.56" 1x GbE, 1xGbE with POE (optional)
PPC-101E 10.1" LCD with Projected Capacitive 10-Point Multitouch Allwinner A40 Cortex™ QuadCore Processor Up to 2GB DDR3 RAM onboard 1x serial, 2x USB2, 1x USB OTG 8GB NAND flash, SATA Mini-PCIe expansion Enclosed PPC10.87" ×7.56" ×1.34" Gigabit LAN, POE, Wi-Fi 802.11 b,g,n , HDMI, GPS, Bluetooth
VOX-104VOX-104 FRONT 10.4" TFT Color WVGA LCD, 800 x 600, 4-Wire Analog Resistive DM&P Vortex86DX2 or Vortex86DX3 800 MHz or 1GHz Up to 2GB DDR3 onboard 4x RS232/422/485, 3x USB2.0 1x SATA PC/104 Open Frame PPC11.92" ×8.03" ×2.45" 1x 10/100 Ethernet, 2x GbE LAN, 16x GPIO, 1x LPT
PPC-6712 11.6" LED Backlight, WXGA 1366x768, 4-Wire Analog Resistive Touch Intel Celeron J1900 2.42 GHz Up to 8GB DDR3L SODIMM 1x COM, 1x USB 3.0, 2x USB 2.0 header 2.5" SATA, mSATA 1x half-size mini-PCIe &1x full size mini-PCIe x1 slot Enclosed PPC11.25" ×7.25" ×2.5" Dual Gig-Lan, Audio line out, VGA, HDMI,
PPC-E4+PPC-E4+ Panel PC Front 4.3 " TFT Color WQVGA LCD, 480 x 272, 4-Wire Analog Resistive Embedded Atmel AT91SAM9G45 400 MHz Up to 256 MB DDR2 RAM 3x RS-232, 1x RS-232/422/485, 1x USB Host, 1x USB OTG SDIO, SDHC/ MMC, Flash Disk none Open Frame PPC4.8" ×3" ×1.2" 10/100 Ethernet, Audio, 16x GPIO

IP Spec Rated PPCs

Product # Video/ Touchscreen CPU Memory Serial Ports Disk Interfaces Bus Dimensions Other I/O
PPC-104T 10" TFT Color LCD, 800 x 600, Analog Resistive DM&P Vortex86DX2 933 MHz or Vortex86DX3 1GHZ up to 2 GB DDR3L onboard 2 x RS232/422/485, 3x USB 2.0 Compact Flash or SATA Slim SSD Internal USB Enclosed PPC10.76" ×8.65" ×1.93" 10/100 Mbps LAN (POE optional) / 10/100/1000 GbE (optional), 16x GPIO (optional), up to 7x RS232

Wide-Temp PPCs

Product # Video/ Touchscreen CPU Memory Serial Ports Disk Interfaces Bus Dimensions Other I/O
HMI-043THMI-043T x86 Panel PC 4.3 " TFT, Color WQVGA LCD, 480 x 272, 4-Wire Analog Resistive DMP Vortex86EXm 400 MHz Up to 256 MB DDR3 RAM Onboard 1x RS-232, 485 or CAN SD Slot or up to 2GB eMMC NAND Flash Memory Onboard N/A Enclosed PPC4.58" ×3.71" ×1.35" Ethernet, POE, HF RFID/NFC, 1x USB 2.0
HMI-043T-OPPC-043T 4.3" Open Frame 4.3” WQVGA TFT LCD, 4-wire Analog Resistive Touch Screen DMP Vortex86EXm 400MHz up to 256MB DDR3 onboard 1x RS-232, 2x RS-485, 1xCAN SD Slot or up to 2GB eMMC NAND Flash Memory Onboard Expansion slots Open Frame PPC4.15" ×2.65" ×0.54" Ethernet, 2x USB2.0, 1x 8-bit GPIO
PPC-07-IMX6MPPC-70-IMX6 7" TFT Color WVGA LCD, 800 x 480, 4-Wire Analog Resistive, HDMI, CSI, DSI NXP i.MX6 1.0GHz ARM Dual or Quad Core Processor Up to 2GB DDR3L RAM, 4GB eMMC Flash onboard 3x RS232 & 1x RS232/422/485 Port, 2x USB 2.0 Host, 1x USB 2.0 OTG MicroSD, mSATA Socket mini-PCIe Socket with SIM Open Frame PPC7.55" ×4.15" 1x GbE LAN, WiFi 802.11 b/g/n, bluetooth 4.1, 16x GPIO lines
PPC-080T 8" TFT Color LCD, 800 x 600, Analog Resistive Intel Processor N2807 (optional N2600) 2 GB SODIMM DDR3L 3 x RS232*, 1x USB3.0, 3x USB 2.0 SATA SSD Hard Drive 2x Mini PCI-E Enclosed PPC8.5" ×7.2" ×2.2" 2 x GBit RJ45 ports
PPC-080E 8" LCD with Projected Capacitive 10-Point Multitouch Allwinner A40 Cortex™ QuadCore Processor 1GB DDR3 1x serial, 2x USB2, 1x USB OTG 8GB NAND flash, SATA Mini-PCIe expansion Enclosed PPC7.91" ×6.32" ×1.4" Gigabit LAN, POE, Wi-Fi 802.11 b,g,n , HDMI, GPS, Bluetooth
PMX-090TPDX-090T Front 9" TFT Color LCD, 1024 x 600, Analog Resistive Vortex86MX+, 1 GHz Up to 1GB DDR2 onboard 1x RS-232/422/485, 2x USB 2.0 1 IDE, Compact Flash Micro SD Mini PC Enclosed PPC9.31" ×5.75" ×1.38" 10/100 Base-T Ethernet2x USB 2.0
PPC-090TPPC-090 Front 9" WSVGA TFT LCD, 1024 x 600 Vortex86DX2, 933 MHz Up to 2GB DDR2 Onboard 2x RS-232 / 422 / 485 SATA Slim DOM Enclosed PPC9.68" ×6.26" ×1.76" Integrated 10/100Mbps Ethernet, Giga Ethernet, Wi-Fi (Optional). 3x USB Ports (Version 2.0) , POE+
PPC-104T 10" TFT Color LCD, 800 x 600, Analog Resistive DM&P Vortex86DX2 933 MHz or Vortex86DX3 1GHZ up to 2 GB DDR3L onboard 2 x RS232/422/485, 3x USB 2.0 Compact Flash or SATA Slim SSD Internal USB Enclosed PPC10.76" ×8.65" ×1.93" 10/100 Mbps LAN (POE optional) / 10/100/1000 GbE (optional), 16x GPIO (optional), up to 7x RS232
PPC-101E 10.1" LCD with Projected Capacitive 10-Point Multitouch Allwinner A40 Cortex™ QuadCore Processor Up to 2GB DDR3 RAM onboard 1x serial, 2x USB2, 1x USB OTG 8GB NAND flash, SATA Mini-PCIe expansion Enclosed PPC10.87" ×7.56" ×1.34" Gigabit LAN, POE, Wi-Fi 802.11 b,g,n , HDMI, GPS, Bluetooth
PPC-150T PPC-150T- Panel PC Front View 15" XGA TFT LCD, 1024x768, Analog Resistive or P-Capacitive Vortex86DX2 or Vortex86DX3 933 MHz Up to 2GB DDR2 onboard 2x RS-232/422/485, 2x USB 2.0 Compact Flash or SATA Slim DOM Enclosed PPC13.97" ×8.22" ×2.16" 10/100 LAN, 10/100/1000 Gig LAN (optional), POE(Optional) 3x USB 2 Ports, 5x serial ports optional
PPC-215E 21.5" LCD with Projected Capacitive 10-Point Multitouch Allwinner A40 Cortex™ QuadCore Processor up to 2 GB DDR3 1x serial, 2x USB2, 1x USB OTG 8GB NAND flash, SATA Mini-PCIe expansion Enclosed PPC20.79" ×12.76" ×165" Gigabit LAN, POE, Wi-Fi 802.11 b,g,n , HDMI, GPS, Bluetooth
PPC-215T 21.5" LCD with Projected Capacitive 10-Point Multitouch, display port Intel® Celeron™ QuadCore J1900 Up to 4GB DDR3 SODIMM 4x COM, 1x USB 3.0, 3x USB 2.0 ports 64GB SATA SSD 2x Mini-PCIe Enclosed PPC20.79" ×12.76" ×2.28" 2x Gigabit LAN, POE, Wi-Fi 802.11 a,b,g,n , HDMI

IoT Panel PCs

Product # Video / Touchscreen CPU Memory Serial Ports Disk Interfaces Bus Dims. Other I/O
DEV-SOM36PPC-04-5D36 Panel PC Front 4.3 " TFT Color WQVGA LCD, 480 x 272, 4-Wire Analog Resistive Atmel ARM Cortex A5 ATSAMA5D36 512 MB of DDR2 SDRAM, 4GB eMMC Flash Onboard 2x RS-232, 1x RS-232/422/485 with Auto RS485, 2x USB 2.0, CAN, SPI MicroSD None 4.8" ×3" ×1.2" 10/100 DP83640 IEEE 1588 PTP LAN & GbE Ethernet, Audio, 16x GPIO
PPC-04-3354PPC-04-3554 Panel PC Front 4.3 " TFT Color WQVGA LCD, 480 x 272, 4-Wire Analog Resistive TI ARM Cortex A8 based Processor AM3354, 512 MB of DDR3 SDRAM, 4GB eMMC Flash Onboard 3x RS-232 with handshaking, 1x RS-232/422/485 with Auto RS485, high-speed SPI with chip selects, I2C SDIO SDHC/ MMC Flash Disk None 4.8" ×3" ×1.2" 10/100 Ethernet, Audio, 16x GPIO

EOL PPCs

Product # Video/ Touchscreen CPU Memory Serial Ports Disk Interfaces Bus Dimensions Other I/O
PPC-1083 PPC-1083 Panel Front View 8.4 ” SVGA HMI 5-wire Analog Resistive Touch Panel PC Intel® Atom™ D2550,
1.86 GHz 		Up to 4 GB DDR3 SODIMM 1x RS-232 & 1x RS-232/422/485 2.5 Inch SATA Hard Disk Drive / CFast™ Slot (Internal) 1x Mini-Card Enclosed PPC9.65" ×7.2" ×2.67" 2x USB 2.0 Ports, 2x 10/100/1000 Base-TX with RJ-45, 2x USB 2.0 Ports
PPC-104T-N270PPC-104T-N270 10" TFT Color LCD, 1024 x768, Analog Resistive Intel Atom N270,
1.6 GHz 		2 GB DDR2 SODIMM 3x COM/RS232 headers 16GB SATA SSD Hard Drive MiniPCI-E Enclosed PPC10.1" ×8" ×1.9" 2x 10/100/1000Mbit RJ45 Ports
PPC-4510PPC-4510 Front 10.1” touch panel 1280x 720 with projected capacitive touch Freescale IMX6,
1 GHz 		Up to 2 GB onboard memory 5x COM SATA (Optional) 4x 50 pin female IO expansion Enclosed PPC10.5" ×6.9" ×2" 4x USB 2.o, 1x 10/100, 4x USB 2.o
PPC-3100SPPC-3100 10.4" TFT SVGA LED Panel with Resistive Touchscreen Intel Celeron N2930 Quad Core CPU,
1.83 GHz 		Up to 8GB DDR3L SODIMM 2x RS232, (1x RS232/422/485) 1x SATA, 1x mSATA 1x MINI PCIe Enclosed PPC10.7" ×8.5" ×1.8" 1x USB 3.0 & 2x USB 2.0, 2x 10/100/1000 Mbps RJ45 Intel I211, 1x USB 3.0 & 2x USB 2.0
PPC-6123PPC-6123 Panel Front View 12.1” XGA (1024 x 768) TFT LCD Display Intel® Atom™ D2550 Dual Core Onboard,
1.86 GHz 		Up to 4 GB DDR3 SODIMM 1x RS-232, 1x RS-232/422/485 1x 2.5 Inch SATA Hard Disk Drive / 1x CFast™ Slot (Internal) 1x Mini-card Enclosed PPC14.6" ×11.2" ×3.42" 2x USB 2.0 Ports, 1x 10/100/1000Base-TX, 2x USB 2.0 Ports
PPC-1123PPC-1123 Panel Front 12.1” XGA HMI TFT-LCD 1024 x 768 Touch Panel PC Intel® Atom™ D2550 Onboard,
1.86 GHz 		Up to 4 GB DDR3 800/1066 RAM Inside 3x S-232 x 3, 1x RS-232/422/485 2.5 Inch SATA Hard Disk Drive / CFast™ Slot (Internal) 1x Mini-Card Enclosed PPC 4x USB 2.0 Ports, 2x 10/100/1000Base-TX with RJ-45, 4x USB 2.0 Ports
PPC-6150 PPC-6150 Panel Front View 15" TFT LCD (LED Backlight) 5-wire Resistive Touch Intel Core i5-3610ME 2.7GHz / Core i3-3120ME 2.4GHz Celeron 1020E 2.2GHz,
2.7 GHz 		Up to 8 GB DDR3 SODIMM 1x RS-232/422/485, 3x RS-232 Storage 1: 2.5 Inch SATA HDD, Storage 2: 2.5 Inch SATA HDD (support Intel RAID function) (optional) Support slim 8X or above DVD +/- RW (optional) 1x PCI + 1x PCIe (default), 2x PCIe x1 (optional), 2x PCI (optional) Enclosed PPC15.6" ×12.5" ×4.15" 3x USB 3.0 Ports / 2x USB 2.0 Ports, 4x Gigabit Gigabit Ethernet, 3x USB 3.0 Ports / 2x USB 2.0 Ports
PPC-4150W 15.6" TFT WXGA LED flat panel with Capacitive touchscreen Intel Atom D2550 10W Dual Core CPU on board,
1.86 GHz 		Up to 4GB SODIMM 4 x Serial ports: 3 x RS-232, 1x RS-232, 422, 485 (Adjustable through BIOS) Supports 1 x 2.5" SATA HDD/SSD and 1x mSATA socket 1x MINI PCle, 1x PClex1 or 1 x PCI Enclosed PPC419.7" ×269" ×59" 5 x USB 2.0 ports (4 in Rear, 1 from right side), 2 x 10/100/1000 Mbps, 5 x USB 2.0 ports (4 in Rear, 1 from right side)
PPC-2153PPC-2153 Panel Front View 15” XGA (1024 x 768) TFT LCD 5-wire Resistive Touch Screen (Sunlight Readable - STT) Intel® Dual Core™ Atom™ D2550 Onboard,
1.86 GHz 		up to 4 GB RAM 2x RS-232, 1x RS-232/422/485 2.5 Inch SATA Hard Disk Drive / CFast™ Slot (Internal) 1x Mini-Card Enclosed PPC15.35" ×12.74" ×3.08" 4x USB 2.0 Ports (2 Front & 2 on Rear), 2x 10/100/1000Base-TX with RJ-45, 4x USB 2.0 Ports (2 Front & 2 on Rear)
PPC-6170 PPC-6170 PANEL FRONT VIEW 17" TFT LCD (LED Backlight) 5-wire Resistive Touch Up to Core i5-36110ME,
2.7 GHz 		Up to 8 GB DDR3L SODIMM 4x COM ports, 1x isolated RS-232/422/485, 3x RS-232 1 x 2.5" SATA HDD/SSD and mSATA 1x PCI, 1x PCIe Enclosed PPC442" ×362" ×113.5" 4x USB 3.0 Ports, 2 x USB 2.0 Ports, 2x Gigabit Ethernet, 4x USB 3.0 Ports, 2 x USB 2.0 Ports
PPC-2173PPC-2173 Panel PC View 17” SXGA (1280 x 1024) TFT LCD 5-wire Resistive Touch Screen Intel® Atom™ D2550,
1.86 GHz 		Up to 4 GB SODIMM 2x RS-232 / 1x RS-232/422/485 2.5 Inch SATA Hard Disk Driver / CFast™ Slot (Internal) 1x Mini-PCIe Enclosed PPC16.56" ×14.08" ×2.87" 2x USB 2.0 Ports, 2x 10/100/1000 Base-T with RJ-45, 2x USB 2.0 Ports
PPC-6152 PPC-6152 Panel Front View 15” XGA (1024 x 768) TFT LCD 5-wire Analog Resistive Touch Screen Intel® Atom™ D525 Dual Core Onboard,
1.8 GHz 		UP to 4GB DDR3 1x RS-232, 1x RS-232/422/485 1x 2.5 Inch SATA Hard Disk Drive / 1x CompactFlash™ Slot 1x Mini-Card Enclosed PPC15.75" ×12.76" ×3.32" 2x USB 2.0 Ports, 1x 10/100/1000Base-TX, 2x USB 2.0 Ports
AFL-08BAFL-08B Front 8 " TFT Color LCD, 800 x 600, Analog Resistive Fanless Atom N270,
1.6 GHz 		1 GB built in, Up to 2 GB SODIMM DDR 1x RS-232, 1x RS-232/422/485 CompactFlash Type II socket, IDE One Mini-PCIe Socket Enclosed PPC9.2" ×7.2" ×1.6" 2x USB 2.0, 2 x RJ-45 Ethernet connectors, 2x USB 2.0
AHP-1122AHP-1122 Front 12.1" TFT Color LCD, 1024 x 768, Analog Resistive Intel® Atom™ D510,
1.66 GHz 		Up to 2GB DDR2 SODIMM 1x RS-232/422/485, 1x RS-232 CompactFlash Type I/II socket, SATA 2x Mini-PCIe Sockets Enclosed PPC12.5" ×9.5" ×2.5" 4x USB 2.0, Dual 10/100/1000 Base-TX Ethernet interface, 4x USB 2.0
PPC-080T-D525PPC-080T-D525 8" TFT Color LCD, 800 x 600, Analog Resistive Intel Atom D525 dual core,
1.8 GHz 		2 GB DDR3 SODIMM 2x COM/RS232 header (1x connected to external COM-connector) 30GB SATA SSD Hard Drive MiniPCI-E Enclosed PPC8.5" ×7.2" ×1.77" 4x USB 2.0, 10/100/1000 Base-T Ethernet, 4x USB 2.0
PPC-106TPPC-106T Front 10.4" TFT Color LCD, 800 x 600, 0.26 pitch, Analog Resistive onboard AMD Geode LX 800,
500 MHz 		Up to 1 GB DDR SODIMM 3x RS-232, 1x RS-232/422/485 1x 2.5" IDE/ CompactFlash Type I/II socket One Mini PCI & One PCI/ISA slot Enclosed PPC13.5" ×10.4" ×3.64" 4x USB 2.0 (2 internal, 2 external), 10/100 Base-T Ethernet interface (Dual LAN Optional), 4x USB 2.0 (2 internal, 2 external)
PPC-E10 PPC-E10 10" TFT, Color WSVGA LCD, 1024 x 600, 4-Wire Analog Resistive TI ARM Cortex A8 based Processor AM3354,
1 GHz 		Up to 512 MB DDR2 RAM, 512MB NAND Flash 3x RS-232 with handshake, 1x RS-232/422/485 with Auto RS485, high-speed SPI with chip selects, I2C SDIO SDHC/ MMC Flash Disk PCD-E12 Open Frame PPC5.76" ×10.25" 2x USB High Speed Host, 1x USB High Speed OTG, 1x 10/100/1000 BaseT Ethernet, 2x USB High Speed Host, 1x USB High Speed OTG
PPC-E4PPC-E4 Panel PC 4.3 " TFT, Color WQVGA LCD, 480 x 272, 4-Wire Analog Resistive Embedded Cirrus EP9307 with Hardware Floating Point Math Engine,
200 MHz 		128 MB SDRAM On-Board max. 2x RS-232 with handshaking, 1x RS-232/422/485, high-speed SPI with chip selects SD, SDHC, Flash Disk none Open Frame PPC4.8" ×3" ×1.2" 2x USB 2.0 Full Speed Hosts, 2x USB 2.0 Full Speed Hosts
PPC-E7PPC-E7 FRONT 7" TFT Color WVGA LCD, 800 x 480, 4-Wire Analog Resistive Embedded Cirrus EP9307 with Hardware Floating Point Math Engine,
200 MHz 		128 MB SDRAM On-Board max. 2x RS-232 with handshaking, 1x RS-232/422/485 with Auto RS485, high-speed SPI with chip selects SD, SDHC, MMC, Flash Disk PCD-E12 Open Frame PPC7.55" ×4.15" ×1.5" 3x USB 2.0, 3x USB 2.0
PPC-E7-9G45PPC-E7+ [3354] 7" TFT Color WVGA LCD, 800 x 480, 4-Wire Analog Resistive Fanless ARM9,
400 MHz 		Up to 256 MB DDR2 RAM 3x RS-232 with handshaking, 1x RS-232/422/485 with Auto RS485, high-speed SPI with chip selects, I2C SDIO SDHC/ MMC Flash Disk PCD-E12 Open Frame PPC7.55" ×4.15" ×1.5" 1x USB 2.0 Host, 1x USB 2.0 OTG Host/Device, 1 x 10/100 BaseT Ethernet Port with on-board PHY, 1x USB 2.0 Host, 1x USB 2.0 OTG Host/Device
PPC-L127TPPC-L127T Front 12.1" TFT Color LCD, 800 x 600, Analog Resistive Embedded Intel® ULV Celeron® M,
1 GHz 		Up to 1 GB DDR DIMM 3x RS-232, 1x RS-232/422/485 CompactFlash Type I/II socket, IDE One Mini PCI & One PCI/ISA slot Enclosed PPC340.5mm ×269.3mm ×70.5mm 6x USB 2.0 (2 internal, 4 external), 10/100 Base-T Ethernet interface, 6x USB 2.0 (2 internal, 4 external)
PPC-L156TPPC-L156T Front 15'' Color TFT LCD 1024 x 768 Analog resistive, Capacitive, and Infrared Embedded Intel® ULV Celeron® M,
1 GHz 		Up to 2GB DDR 3x RS-232, 1x RS-232/422/485 CompactFlash Type I/II socket 2.5" IDE One Mini PCI & One PCI/ISA slot Enclosed PPC16.3" ×13.1" ×3" 4x USB 2.0 (2 internal, 2 external), 10/100 Base-T Ethernet interface, 4x USB 2.0 (2 internal, 2 external)
PPC-S154TPPC-S154T 15" TFT Color LCD, 1024 x 768, 0.297 pitch, Analog Resistive (Optional) 478 Socket based Mobile Intel Pentium 4 Processor-M CPU,
1.7 GHz 		Up to 1 GB DDR SDRAM 2x RS-232 1x FDD, 1x 2.5" IDE, CD-ROM, DVD, CompactFlash Type II socket One Mini-PCI Socket Enclosed PPC14.76" ×11.77" ×1.93" 4x USB 2.0, 10/100 Base-T Ethernet interface, 4x USB 2.0
VOX-121VOX-121 FRONT 12.1" TFT Color WVGA LCD, 800 x 600, 4-Wire Analog Resistive Fanless Vortex86DX 486 DX,
800 MHz 		Up to 1 GB DDR2 RAM On-Board 5x RS-232 with handshaking, 1x RS-232/422/485 1x 2.5" IDE, CompactFlash™ Type I/II socket USB Open Frame PPC11.92" ×8.03" ×2.45" 3x USB 2.0 Ports, 10/100 Base-T Ethernet with on-Board RJ-45 connector, 3x USB 2.0 Ports
