Intro to the EMAC OE SDK.
The SoM-iMX6 is an ARM System on Module (SoM) based on the NXP (Freescale) i.MX 6 ARM Cortex A9 Solo, Dual or Quad Core processor. Designed and manufactured in the USA, this wide temperature, fanless ARM 1GHz SoM has 10/100/1000 BaseT Ethernet included along with 4 serial ports. It utilizes up to 4GB of eMMC Flash, up to 16MB of serial data flash, and up to 2GB of LP DDR2 RAM. A SoM is a small embedded module that contains the core of a microprocessor system.
Designed and manufactured in the USA, the SoM-iMX6U is an ultra low power System on Module (SoM) designed to plug into an EMAC carrier board that contains all the connectors and I/O required for a system. The SoM-iMX6U is based on the Freescale/NXP i.MX6 UltraLite Cortex A7 processor and has ARM Sleep Mode of 3.5mA.
A SoM is a small embedded module that contains the core of a microprocessor system. The SoM-iMX6U is industrial wide temperature, ultra-low power 528 MHz module with 4GB of eMMC Flash, 8MB of serial data flash, and 512MB of LP DDR2 RAM. The module has 10/100 BaseT Ethernet, 5x serial ports (4x without handshake and 1x with handshake). The recommended development / carrier board is the SoM-112 or SoM-150 carrier board.
- EMAC OEM products are designed and manufactured at our facility in the United States.
- EMAC provides both x86 and RISC/ARM based products & peripherals.
- EMAC can provide off-the-shelf, custom and semi custom Single Board Computers (SBCs), Panel-PCs (PPCs), System on Modules (SoMs) and Carrier boar
