SIB-KA202

  • CPU Intel® Atom™ E3845 Quad-Core 1.91 GHz
  • 4GB DDR3L ECC Onboard
  • 2x RS232/RS422/RS485
  • 2x USB 2.0
  • 2x Gigabit Ethernet

SIB-KA202 Fanless Box PC for Connected Applications. IoT Ready - Simply Connect

Features

  • CPU Intel® Atom™ E3845 Quad-Core 1.91 GHz
  • 4GB DDR3L ECC Soldered Onboard
  • Up to 2x RS232/RS422/RS485
  • 2x USB 2.0
  • 2x 10/100/1000 Ethernet
  • HDMI Video out
  • Intel® HD Graphics: Max Resolution Full HD (1920 x 1080)
  • CHIPSET Integrated
  • Phoenix SecureCore™ BIOS
  • WATCHDOG TIMER
  • SIM Card slot
  • 1x Mini PCIe Full-Size
  • 1x Micro SD
  • WIN 8.1/ Yocto
  • 6,5 V DC to 32 V DC
  • Adapter AC to DC 24 V / 2.5 A (60W) optional
  • Typical 5W, Max. 15W
  • DIN RAIL, Desktop, Cabinet
  • Cooling Fan
  • Operating Temperature: Industrial grade -40°C to +75°C (-40°F to 167°F)
  • Humidity: 93% @ at 40°C non-condensing
  • Vibration operational: IEC 60068-2-6 10 - 500 Hz, 2 G
  • Shock operational: IEC 60068-2-27 half sine 11 ms 15 G
  • 150 x 57 x 95 mm (5.91" x 2.24" x 3.74")
  • 1 kg (2.20 lbs)

Overview

SIB-KA202 Fanless Box PC for Connected Applications. IoT Ready - Simply Connect

Manuals
kbox-a-20x_user_guide_v1.0_en.pdf
Download (PDF)
Data Sheets
datasheet_kbox-a-202.pdf
Download (PDF)

Specifications

Processor
CPU
CPU Intel® Atom™ E3845 Quad Core
Clock Speed
1.91 GHz
Processor Misc.

CPU Intel® Atom™ E3845 Quad Core
Memory
RAM Type
DDR3L ECC Soldered Onboard
Primary Flash
Onboard
Secondary Flash
MicroSD
BIOS/ Bootloader
AMI uEFI
Primary IO
Disk Interface
MicroSD
Video Out
HDMI
Ethernet
2x 10/100/1000 Mbps
USB
2x USB 2.0
Serial Ports
2x RS232/RS422/RS485
Secondary IO
Power Supply
6.5 V DC to 32 V DC
Secondary I/O Misc.

6,5 V DC to 32 V DC
ADAPTER AC to DC 24 V / 2.5 A (60W) optional
Misc
Operating Systems
EMAC OE Linux, WES 7 - Windows Embedded Standard 7, Windows 10 IoT Enterprise LTSC

Mechanical and Environmental

Dimensions
Size
5.91" ×2.24" ×3.74" (150mm × 56mm × 94mm)
Weight
1 kg
Power Requirements
Voltage
24 V
Power Misc.

24 V / 2.5 A
Environmental
Low Operating Temperature-40 C (-40 F)
High Operating Temperature75 C (167 F)
Upper Operating Humidity
93%
Environmental Misc.

Fanless
Industrial grade -40°C to +75°C (-40°F to 167°F)
93% @ at 40°C non-condensing

Pricing

Pricing correct as of January 2021. Please contact EMAC for Current Pricing and Lead Time. Due to volatility in the electronics industry pricing is subject to change.

OEM / Quantity Pricing Available on Request - Less Services

(Single Unit Pricing. Includes: Integration, Setup,Testing, & Enhanced Support)

Product # Description Price
SIB-KA202-400-R KBox-A-202, CPU Intel® Atom™ E3845 Quad Core 1.91 GHz, 4GB RAM, 16GB Flash, 2x COM, 2x Gig LAN, HDMI Call
SIB-KA202-4W0-R KBox-A-202, CPU Intel® Atom™ E3845 Quad Core 1.91 GHz, 4GB RAM, 16GB Flash, 2xCOM, 2x Gig LAN, WiFi, HDMI Call

Peripheral Options

Product # Description Price
Operating Systems
SL05x-XON-xx EMAC OE Linux 5.x for x86 (Free installation at time of purchase of SBC & media) Free
SX300-000-0000D Windows Embedded Standard 2009 (WES09) & License (Base configured installation included with License, Flash and SBC purchase; SOLD ONLY WITH HARD DRIVE OR FLASH DRIVE MEDIA) $125.00
S7000-NOL-00020 Windows Embedded Standard 7 (WES7) & License. SOLD ONLY WITH HARD DRIVE OR FLASH DRIVE MEDIA (EOL 10/13/2020) $125.00

Additional Options
