Terminal Boards


PCD-3920

  • Low cost universal DIN-rail mounting screw terminal module for 20-pin flat cable connector.
  • Screw-clamp terminal blocks allow easy and reliable connections
  • Case dimensions: 77.5 mm (W) x 67.5 mm (L) x 51 mm (H) (3.1" x 2.7" x 2.0")
  • Compatible With: PCD-E12 I/O Module, MicroPac Line, EPAC Line, or Universal Trainer

PCD-3950

  • Low cost universal DIN-rail mounting screw terminal module for 50-pin flat cable connector.
  • Screw-clamp terminal blocks allow easy and reliable connections
  • Case dimensions: 77.5 mm (W) x 146.3 mm (L) x 51 mm (H) (3.1" x 5.8" x 2.0")
  • Compatible With: PCD-E12 I/O Module, MicroPac Line, EPAC Line, 32 Line Parallel I/O Board, or Universal Trainer

PCD-39E00

  • Screw-clamp terminal blocks allow easy and reliable connections
  • Small PC/104 form factor
  • Dimensions: 3.55"(L) x 3.775"(W) (90mm x 96mm)
  • Compatible With: PCM-37E12, PCD-E12 I/O Module, and iPac Line of SBCs

Pricing

Product # Variations Price
PCD-39E00-000 Screw Terminal Board Kit containing 40 pin and 50 pin connection cables ***See Product GPIO*** (Minimum Order Quantity is 50 pieces. Evaluation quantities may be available - Please inquire for current stock availability). $50.00
PCD-3950 50-pin Wire Screw Terminal, with Flat Cable $85.00
PCD-3920 20-pin Wire Screw Terminal Block, with Flat Cable $35.00
