SOM-DB4700
- ETX Development Board
- ATX form factor
- Display type: LVDS, DVI, VGA, TV out
- Expansion: 2 Express Card, 3 PCI, 1 Mini PCl, 1 ISA bus slot
21spi11122 The SoM-DB4700 is versatile SoM Carrier/Socket board ideal for evaluation and early development work. This Carrier is designed to work with all ETX type SOMs. The SoM-DB4700 provides access to all the SoM's I/O through on-board connectors.
Although a good deal of customers will want a Carrier that is unique and is designed specifically for their application, the SoM-DB4700 when coupled with a ETX SoM makes for a nice ATX compatible embedded PC.
Features
LCD- TTL/LVDS (depends on CPU module)
VGA- 1
TV out- 1
Dual Display- TTL/LVDS, VGA, TV out
Ethernet- 1 x 10/100
Audio- AC97
PCI- 3
Mini PCI- 1
ISA- 1
EIDE- 1 x 40 pin + 1 x 44 pin
Serial- 4 COM ports, 3x RS-232, 1 x RS-232/422/485
USB- 4 x USB 2.0
LPT/FDD- 1
KB/MS- 1
CF-1
System Fan-1
SMBus- 1
12C- 1
Port 80- 1
Power Type- ATX Mode
Operating Temperature- 0 ~ 60 C
Humidity- Operating: 40 C @ 95% relative Humidity, non-condensing, Storage: 60 C @ 95% relative humidity, non-condensing
Dimensions 12" x 7.5"
Overview
The SoM-DB4700 is versatile SoM Carrier/Socket board ideal for evaluation and early development work. This Carrier is designed to work with all ETX type SOMs. The SoM-DB4700 provides access to all the SoM's I/O through on-board connectors.
Although a good deal of customers will want a Carrier that is unique and is designed specifically for their application, the SoM-DB4700 when coupled with a ETX SoM makes for a nice ATX compatible embedded PC.
| Manuals | |
|---|---|
| SOM-DB4700_user_manual_Ed1.pdf | Download (PDF) |
| Data Sheets | |
|---|---|
| SOM-DB4700_DS.pdf | Download (PDF) |
Specifications
| Memory | |
|---|---|
| Primary Flash | 1x Compact Flash Slot |
| Primary IO | |
|---|---|
| Disk Interface | 1x EIDE- 40 pin + 1X 44 pin |
| Audio | AC97 |
| Video Out | TTL LVDS VGA - Depends on CPU Module |
| Ethernet | 1x 10/100 |
| USB | 4x USB 2.0 |
| Serial Ports | 3x RS232. 1x RS232/422/485 |
| Primary I/O Misc. |
|
| Secondary IO | |
|---|---|
| LPT Port | Yes
|
| Misc | |
|---|---|
| SOM Type | ETX Carrier Boards |
Mechanical and Environmental
| Dimensions | |
|---|---|
| Size | 12" ×7.5" (304mm × 190mm) |
| Power Requirements | |
|---|---|
| Power Misc. | Power Type- ATX mode
|
| Environmental | |
|---|---|
| Low Operating Temperature | 0 C (32 F) |
| High Operating Temperature | 60 C (140 F) |
| Environmental Misc. | Humidity- Operating: 40 C @ 95% relative humidity, non- condensing, Storage: 60 C @ 95% relative humidity, non-condensing |
Pricing
Pricing correct as of January 2021. Please contact EMAC for Current Pricing and Lead Time. Due to volatility in the electronics industry pricing is subject to change.
OEM / Quantity Pricing Available on Request - Less Services
(Single Unit Pricing. Includes: Integration, Setup,Testing, & Enhanced Support)
| Product # | Description | Price |
|---|---|---|
| SOM-DB4700-00A1E | ETX development carrier board | $278.00 |
