PCM-3810I

The PCM-3810I is a PCI-104 multifunction card for IBM PC/XT/AT or compatible computers. It offers the five most desired measurement and control functions:

• 12-bit A/D conversion
• 12-bit D/A conversion
• Digital input
• Digital output
• Timer/counter

Features

  • 16 single-ended or 8 differential A/D inputs, switch selectable
  • 12-bit A/D converter, up to 250 kHz sampling rate
  • Programmable gain for each input channel
  • Automatic channel/gain scanning
  • Onboard ring buffer for analog input and output
  • Software selectable Bipolar/Unipolar analog input ranges
  • 16 digital inputs and 16 digital outputs, TTL compatible
  • Two 12-bit analog output channels
  • Onboard programmable counter
  • Three 24-bit event counters
  • BoardID switch

Overview

The PCM-3810I is a PCI-104 multifunction card for IBM PC/XT/AT or compatible computers. It offers the five most desired measurement and control functions:

• 12-bit A/D conversion
• 12-bit D/A conversion
• Digital input
• Digital output
• Timer/counter

A programmable-gain instrument amplifier lets you acquire different input signals without external signal conditioning. An onboard 4k word FIFO buffer provides high-speed data transfer and predictable performance under Windows. Automatic channel scanning circuitry and onboard SRAM let you perform multiple-channel A/D conversion andindividual gains for each channel.



Specifications

Characteristics
Module

Analog Input

  • Channels: 16 single-ended or 8 differential or combination
  • Resolution: 12 bits
  • Max. Sampling Rate: 250 kS/s
  • Ring Buffer Size: 4,096 samples
  • Input Protect: 30 Vp-p
  • Sampling Mode: Polling, pacer, double-clock, or external TTL trigger
  • Trigger Mode: Pre-trigger, post-trigger, delay-trigger, about-trigger
  • Input Range and Gain List:
    Gain
    0.5
    1
    2
    4
    8
    Unipolar
    N/A
    0 ~10
    0 ~ 5
    0 ~ 2.5
    0 ~ 1.25

    Bipolar

    ±10
    ±5
    ±2.5
    ±1.25
    ±0.625

Analog Output

  • Channels: 2
  • Power Consumption: + 5 V @ 300 mA (typical)
  • Output Range: Internal Reference (V): 0 ~ 5, 0 ~ 10, ±5, ±10 External Reference: 0 ~ +x V @ +x V (-10 ≤ x ≤ 10)  -x ~ +x V @ +x V (-10 ≤ x ≤ 10)
  • Resolution: 12 bits
  • Output Rate: 250 kS/s
  • Ring Buffer Size: 4,096 samples
  • Slew Rate: 20 V/µs
  • Operation Mode: Software polling, continuous out

Digital Input/Output

  • Channels: 16
  • Compatibility: 5V/TTL

Mechanical

  • Board Dimensions: 96 mm x 90 mm (3.77" x 3.54") (L x W)
  • Weight: 102 g (0.224 lbs.)

Pricing

(Single Unit Pricing. Includes: Integration, Setup,Testing, & Enhanced Support)

Product # Description Price
PCM-3810I-0 16 Channel PCI-104 Module Call
