SoM-9M10M ARM System on Module


  • Atmel ARM9 Jazelle AT91SAM9G45 or AT91SAM9M10 400Mhz Processor
  • 5 Serial ports, 4 with handshake
  • 1 USB 2.0 (High Speed) Host port
  • Up to 128 MB of DDR2 RAM
  • Up to 128 MB of SDRAM

Receive consultation or quotes about this product from our sales staff.

Request a quote

The SoM-9M10 is a System-on-Module (SoM) based on either the Atmel ARM9 AT91SAM9G45 or AT91SAM9M10 processor. This Fanless ARM9, 400 MHz SoM has an Ethernet PHY included along with 4 serial ports. It utilizes up to 256MB of external DDR2 / SDRAM, 1GB of NAND Flash and includes an MMU which allows it to run Linux Operating System. A SoM is a small embedded module that contains the core of a microprocessor system.

Features


  • Small, 200-pin SODIMM form factor (2.66" x 2.375")
  • Atmel ARM9 Jazelle AT91SAM9G45 or AT91SAM9M10 400Mhz Processor
  • 10/100BaseT Ethernet with on-board PHY
  • 5 Serial ports, 4 with handshake
  • 1 USB 2.0 (High Speed) Host port
  • 1 USB 2.0 (High Speed) Host/Device (USB OTG) port
  • Up to 128 MB of DDR2 RAM
  • Up to 128 MB of SDRAM
  • Up to 1 GB of NAND Flash
  • Up to 8 MB of Serial Data Flash
  • Battery backed Real Time Clock
  • On-Module Micro SD Card Socket
  • SD/MMC Flash Card Interface
  • 2 I2C and 2 SPI ports
  • 2 I2S Audio ports
  • Image Sensor Interface (ISI), ITU-R BT 601/656
  • Timer/Counters and Pulse Width Modulation (PWM) ports
  • 8 Channel, 10-bit Analog-to-Digital converter with 4-wire Touchscreen Interface
  • Graphic LCD Interface with 2D acceleration up to 1280 x 860 Resolution
  • Multi-format Video Decoder (SoM-9M10 only)
  • True Random Number Generator
  • Typical power requirement less than 1 Watt
  • JTAG for debug, including real-time trace
  • FREE Eclipse IDE with GCC & GDB development tools
  • Linux
  • Green Hills Integrity BSP in development

Overview


The SoM-9M10 is a System-on-Module (SoM) based on either the Atmel ARM9 AT91SAM9G45 or AT91SAM9M10 processor. This Fanless ARM9, 400 MHz SoM has an Ethernet PHY included along with 4 serial ports. It utilizes up to 256MB of external DDR2 / SDRAM, 1GB of NAND Flash and includes an MMU which allows it to run Linux Operating System. A SoM is a small embedded module that contains the core of a microprocessor system.

Using the same small 200 pin SODIMM form-factor utilized by other EMAC SoM modules, the SoM-9M10 is the ideal processor engine for your next design. All of the ARM processor core is included on this tiny board including: Flash, Memory, Serial Ports, Ethernet, I2S Audio, PWMs, Timer/Counters, A/D, digital I/O lines, video, Clock/Calendar, and more.

The SoM-9M10 is designed to plug into a carrier board that contains all the connectors and any custom I/O required for the application. This approach allows the customer or EMAC, to design a Custom Carrier Board that meets the customer's I/O, dimensional, and connector requirements without having to worry about the processor, memory, and standard I/O functionality. With this System on Module approach, a semi-custom hardware platform can be developed in as little as a month.

In addition to the option of the developing a Carrier board, one can be purchased off-the-shelf from EMAC. EMAC provides off-the-shelf Carrier boards that feature A/D, D/A, MMC/SD card, keypad, LCD, Touchscreen, and Audio interfaces. The recommended off-the-shelf Carrier Board for the SoM-9M10 is the SoM-200ES which allows the user to immediately start coding their application using the powerful Linux Operating System and Tools.

The System on Module approach provides the flexibility of a fully customized product at a greatly reduced cost.

Manuals
SOM-9G45-9M10_User_Manual.pdf
Data Sheets
SoM-9G45-Datasheet.pdf

Specifications


Processor
CPU
Embedded Atmel AT91SAM9M10
Clock Speed
400 MHz
Processor Misc.

System Reset: Supervisor with external Reset Button provision

Memory
RAM
256 MB
RAM Type
DDR2
Primary Flash
1GB NAND Flash
Secondary Flash
16 MB of Serial Data Flash
Primary IO
GPIO
32x GPIO's with 16 ma. drive when used as an output
Audio
2x I2S Synchronous Serial Controllers with analog interface support
Video Out
LCD Video Interface with up 1280 x 860 resolution with 2D acceleration & Video CODECs
Ethernet
1x 10/100 BaseT Ethernet
USB
1x USB 2.0 High Speed Host, 1x USB 2.0 High Speed Host/Device (USB OTG)
Serial Ports
5x Serial Ports (4x with RTS/CTS handshake, 1x RS485)
Secondary IO
SPI
2x High-Speed SPI ports with Chip Selects
Timers/ Counters/ PWM
2x 3 channel, 16-bit timers/counters with capture, compare, and PWM, 20-bit interval timer plus 12-bit interval counter
Touch
10-Bit 4-wire analog resistive Touchscreen
I2C
2x multi-mode I2C port
Expansion
Bus
Local ARM AT91SAM9G45 / 9M10 Bus accessible through SODIMM provides 22 address lines, 16 data bus lines, and control lines
Analog
Analog Misc.
  • Analog I/O: 8 channel, 10-bit Analog-to-Digital converter (ADC), with 4 channels utilized for 4-wire touchscreen interface
  • Power: Power Management Controller allows selectively shutting down on processor I/O functionality and running from a slow clock
Misc
Operating Systems
EMAC OE Linux
SOM Type
Microcontroller SODIMM Modules

Mechanical and Environmental


Dimensions
Size
2.66" ×2.375" (67mm × 60mm)
Power Requirements
Voltage
3.3 V
Typical Voltage
3.3 V
Typical Current
270 mA
Max Boot Current
300 mA
Constant Busy Loop Current
290 mA
Idle Current
270 mA
Power Misc.
  • Constant busy loop with Ethernet PHY disabled: 235 mA
  • APM sleep mode using slow clock with Ethernet PHY disabled: 70 mA.
  • APM sleep mode using slow clock with Ethernet PHY enabled: 105 mA
Environmental
Low Operating Temperature-40 C (-40 F)
High Operating Temperature85 C (185 F)
Upper Operating Humidity
90%

Pricing


OEM / Quantity Pricing Available on Request - Less Services

(Single Unit Pricing. Includes: Integration, Setup,Testing, & Enhanced Support)

Product # Description Price
Stock
SoM-9M10M-130 w/ AT91SAM9M10 CPU, 1 GB FLASH 256 MB RAM $250.00

Carrier Board Options


Product #VariationPrice
SoM-200ES-000 Standard Carrier Board with CAN, PLD & 4.3" LCD $245.00
SoM-200ES-001 Deluxe Carrier Board with Audio, CAN, PLD & 4.3" LCD $295.00
SoM-200ES-007 Bare-Bones Carrier Board, with CAN, without PLD & LCD $145.00
SOM-200GS-000 Standard 200-pin Carrier with SD Card, Audio, CAN, PLD & 4.3" LCD $245.00
SOM-200GS-001 Deluxe 200-pin Carrier with WiFi, Audio, CAN, PLD & 4.3" LCD, without SD Card Socket $295.00
SOM-200GS-007 Bare Bones 200-pin Carrier w/SD Card & CAN, without Audio, PLD & LCD $145.00
SoM-212ES-000 Standard Carrier Board with Touch Screen $200.00
SoM-212ES-003 Deluxe Carrier Board with Touch Screen, POE, and Stereo Audio $250.00
SoM-212ES-007 Bare Bones Carrier Board $110.00
SoM-250ES-000 Standard Carrier Board with CAN, Audio, 7" LCD & Touch Screen $399.00
SoM-250ES-001 Deluxe Carrier Board with CAN, Audio, 10" LVDS LCD & Touch Screen $445.00
SoM-250ES-007 Bare-Bones Carrier Board, no LCD $199.00

Peripheral Options


Product # Description Price
Operating Systems
SL040-AON-00010 EMAC OE Linux 4.x for ARM Free
SC600-000-0010D Windows CE 6.0 Pro License SOLD ONLY WITH HARD DRIVE OR FLASH DRIVE MEDIA $25.00
