SoM-6763


  • Intel® Atom processor
  • Supports DDR2 SODIMM up to 2 GB (N450) & 4 GB (D510)
  • Supports 8 USB 2.0 ports
  • Supports 5 PCIe x 1, 4 PCI masters, LPC, 3 SATAII, EIDE

Receive consultation or quotes about this product from our sales staff.

Request a quote

SOM-6763 is an embedded COM-Micro Type 2 CPU module that fully complies with the PCI Industrial Computer Manufactures PICMG COM Express standard. The new CPU module supports Intel N450 and D510 processors with ICH8M chipset which supports Intel Embedded Gen3.5 + GFX Core, MPEG2 Decode in HW, PCI Express and SATA interfaces. In a basic form factor of 95mm x 95mm, the SOM-6763 provides a scalable high performance and easy to integrate solution for customers' applications by utilizing a plug-in CPU module on an application-specific customer solution board.

Features


  • Intel® Atom processor
  • Supports 2 DDR2 SODIMM up to 2 GB
  • Intel® System Controller Hub US15W
  • Supports 8 USB 2.0 ports
  • Intel 82567V Gigabit Ethernet
  • Supports 5 PCIe x 1, 4 PCI masters, LPC, 3 SATAII, EIDE

Overview


SOM-6763 is an embedded COM-Micro Type 2 CPU module that fully complies with the PCI Industrial Computer Manufactures PICMG COM Express standard. The new CPU module supports Intel N450 and D510 processors with ICH8M chipset which supports Intel Embedded Gen3.5 + GFX Core, MPEG2 Decode in HW, PCI Express and SATA interfaces. In a basic form factor of 95mm x 95mm, the SOM-6763 provides a scalable high performance and easy to integrate solution for customers' applications by utilizing a plug-in CPU module on an application-specific customer solution board. The SOM-6763 with advanced I/O capacity incorporates serial differential signaling technologies such as PCI Express, Serial ATA, USB 2.0, LVDS and HD Audio interfaces. SOM-6763 offers design partners more choices for their own applications needing higher computing speeds while maintaining a compact form factor.

SOM-6763 complies with the "Green Function" standard and supports Doze, Standby and Suspend modes. The small size (95 mm x 95 mm) and use of one high capacity connector based on the proven COM-Micro form factor, allow the COM-Micro modules to be easily and securely mounted onto a customized solution board or our standard SOM-DB5700 development board.

The SOM-6763 is a highly integrated multimedia COM module that combines audio, video, and network functions. It provides excellent performance through the Intel N450 and D510 processors, single channel LVDS interface for middle size TFT LCD display, DDR2 memory up to 2 GB (N450) or 4GB (D510), high definition audio interface (AC97/Azalia). On-board devices utilize PCIe technology to achieve outstanding computing performance.

Manuals
som-6763.pdf
SOM-6763_B1_user_manual_ed1.pdf
Data Sheets
SOM-6763_DS.pdf
SOM-6763_B1_DS.pdf

Specifications


Processor
CPU
Intel Atom Processor single N450/ dual D510
Clock Speed
1.66 GHz
Memory
RAM
2 GB
RAM Type
DDR2
BIOS/ Bootloader
AMI 16 Mbit Flash BIOS
Memory Misc.
  • System Memory: 1 x 200-pin SODIMM socket, DDR2 667 MHz up to 2 GB (x 2 w/ D510)
  • System Chipset: ICH8M
Primary IO
GPIO
8-bit GPIO
Disk Interface
1x EIDE Channels (Ultra DMA 100)
Audio
High definition audio interface
Ethernet
Intel 82567V Gigabit Ethernet 1000Base-T standard
USB
8x USB 2.0
Serial Ports
3 x SATAII
Primary I/O Misc.

Display

  • Chipset: Intel ICH8-M, Gen 3.5 DX9, MPEG2 Decode controller
  • Memory Size: Share system memory up to 256MB
  • Display type: Dual display supports CRT and LVDS
      Supports 18-bit single channel LVDS interface
  • Display mode:
    CRT Mode: Supports up to 1400 x 1050 (N450), 2048 x 1536 (D510)
    LCD Mode: Support up to 1366 x 768
Secondary IO
Expansion
Bus
COM Express Type 2
Misc
SOM Type
COM Express Modules

Mechanical and Environmental


Dimensions
Size
3.74" ×3.74" (94mm × 94mm)
Power Requirements
Power Misc.
  • Power Supply Voltage: +12 V and +5 VSB for ATX, +12V for AT
  • Power Requirements :+12 V @ 0.67 A (6763N), +12 V @ 0.93 A (6763D)
    Typical: (1 GB DDRII 667)
Environmental
Low Operating Temperature0 C (32 F)
High Operating Temperature60 C (140 F)
Upper Operating Humidity
90%

Pricing


OEM / Quantity Pricing Available on Request - Less Services

(Single Unit Pricing. Includes: Integration, Setup,Testing, & Enhanced Support)

Product # Description Price
SoM-6763D ATOM D510 1.66 GHz /LVDS/vga/GLAn/audio $324.00
SoM-6763DZ ATOM D510 1.66 GHz /LVDS/vga/GLAn/audio/Wide Temp $404.00
SoM-6763DZ2 ATOM D510 1.66 GHz /LVDS/vga/GLAn/audio/Ind. Temp $509.00
SoM-6763N ATOM N450 1.66 GHz /LVDS/vga/GLAn/audio $315.00
SoM-6763NZ ATOM N450 1.66 GHz /LVDS/vga/GLAn/audio/Wide Temp $384.00
SoM-6763NZ2 ATOM N450 1.66 GHz /LVDS/vga/GLAn/audio/Ind. Temp $489.00

Carrier Board Options


Product #VariationPrice
SoM-DB5700-0 COM express development carrier board $315.00
