PCM-3730i


PCM-3730I is a 32-channel isolated digital input/output card for the PCI-104 bus. the isolated digital input channels are ideal for digital input in noisy environments or with floating potentials. The following sections of this chapter will provide further information about features, installation guide, together with some brief information on software and accessories for the PCM-3730I card.

Features


  • Opto-isolated 8 DI and 8 DO channels
  • High output driving capacity
  • High- Voltage isolation on isolated I/O channels (2500 VDC)
  • Interrupt handling capacity
  • 2 x 20-pin connector for isolated input channels and output channels
  • Keep digital output values after system reset

Overview


PCM-3730I is a 32-channel isolated digital input/output card for the PCI-104 bus. the isolated digital input channels are ideal for digital input in noisy environments or with floating potentials. The following sections of this chapter will provide further information about features, installation guide, together with some brief information on software and accessories for the PCM-3730I card.

Specifications


Characteristics
Module

Isolated Digital I/O

  • Channels: Opto-Isolated 16DI and 16DO channels
  • Input resistance: 2000 Ohms
  • Output Voltage: Open collector 5 to 30 VDC
  • Output sink current: 200 mA max.
  • Isolation Voltage: 2500 VDC
  • Over Current Protection: 1.6 A per 8 channels

General

  • Connectors: 2 x 20-pin box headers
  • Operating Temperature: -20 ~ 70° C (-4 ~ 158° F)
  • Storage Temperature -50 ~ 120° C (-58~248° F)

Pricing


(Single Unit Pricing. Includes: Integration, Setup,Testing, & Enhanced Support)

Product # Description Price
PCM-3730I-0 32-Channel Isolated DIO PCI/104 Module $203.00
