PCM-5315
- Fanless AMD Geode LX800/900 500/600 Mhz Processor
- Up to 1GB SDRAM Memory
- 1920x1440@24bpp Resolution w/ shared memory up to 254MB
- MiniPCI & PC/104 Expansion
Receive consultation or quotes about this product from our sales staff.
Request a quoteThe PCM-5315 is based on the AMD Geode LX800/900 500/600 Mhz CPU and is designed to provide the ideal combination of low power, great performance, widely expanded interfaces and small size for applications that require a small form factor and lower-scale processor support. **CompactFlash card and RAM not included.**
Features
- Onboard AMD Geode LX800/900 500/600 Mhz Processor
- Fanless Operation
- 24-bit TTL/LVDS TFT LCD
- Supports DDR Memory
- Supports Type II CompactFlash
- Supports Mini PCI & PC/104
- Dual 10/100-Base-TX Ethernet Ports
- 8-bit Programmable Digital I/O Lines
- Optional Cable kit "CBK-11-5315-00 " includes:
- Audio Cable
- Keyboard & Mouse Cable
- USB Cable
- Serial Port Cable
- Parallel Port Cable
- IDE Cable 3.5”
- Floppy Cable
Overview
The PCM-5315 is based on the AMD Geode LX800/900 500/600 Mhz CPU and is designed to provide the ideal combination of low power, great performance, widely expanded interfaces and small size for applications that require a small form factor and lower-scale processor support.
The PCM-5315 features DDR SDRAM support up to 1GB, up to 1920x1440@24bpp video resolution with shared system memory up to 254MB that makes the PCM-5315 suitable for applications that require superior computing and graphic display performance. PCM-5315 also features PC/104 and Mini PCI expansion interfaces that work with a wide range of EMAC's PC/104 and Mini PCI peripheral modules. This expansion capability makes the PCM-5315 very flexible allowing it to adapt to legacy PC/104 devices as well as newer middle-to-high level Mini PCI devices.
The PCM-5315 is an ideal board for applications such as data acquisition, industrial control, thin client applications and other uses that leverage low-power consumption with optimized processor performance.
**CompactFlash card and RAM not included.**
| Manuals | |
|---|---|
| pcm-5315ab.pdf | Download (PDF) |
| pcm-5315a.pdf | Download (PDF) |
| Data Sheets | |
|---|---|
| GENE-5315 Rev.A.pdf | Download (PDF) |
Specifications
| Processor | |
|---|---|
| CPU | AMD Geode LX800/900 Fanless 500/600 MHz |
| Processor Misc. | Chipset: AMD Geode LX + AMD CS5536 |
| Memory | |
|---|---|
| RAM | Up to 1GB SDRAM |
| Primary Flash | supports one internal Type II CompactFlash™ socket |
| BIOS/ Bootloader | AWARD 512KB FLASH BIOS |
| Memory Misc. |
|
| Primary IO | |
|---|---|
| Disk Interface | 1x EIDE (UDMA 33) supporting 2 IDE devices |
| Audio | mic-In/line-in/line-out |
| Video Out | CX5536 CRT/LCD 1 - 16 MB Shared |
| Ethernet | Realtek RTL8129DL 10/100 Base-T with 2x RJ-45 connectors |
| USB | 4x USB 2.0 |
| Serial Ports | 1x RS-232, 1x RS-232/422/485, 1x Parallel SPP/EPP/ECP |
| Primary I/O Misc. |
|
| Secondary IO | |
|---|---|
| PS/2 | Yes
|
| Display | |
|---|---|
| Display Type | Simultaneously supports both CRT and 24-bit TFT LCD displays |
| Chipset | AMD Geode + TI SN75LVDS83 |
| Resolution | Up to 1920 x 1440 @ 24bpp for CRT & Up to 1600 x 1200 @ 24bpp for LCD |
| Expansion | |
|---|---|
| Bus Expansion | 1x PC/104, 1x Type Mini PCI |
| Misc | |
|---|---|
| Operating Systems | EMAC OE Linux, Windows Embedded Standard 2009 / WES09 (Windows XPE ), ROM-DOS 6.22 / MS-DOS 6.22 |
Mechanical and Environmental
| Dimensions | |
|---|---|
| Size | 5.75" ×4" (146mm × 101mm) |
| Weight | 400 g (0 lbs) |
| Power Requirements | |
|---|---|
| Typical Voltage | 5 V |
| Typical Current | 1.5 A |
| Power Misc. | Power Supply Type: AT/ATX |
| Environmental | |
|---|---|
| Low Operating Temperature | 0 C (32 F) |
| High Operating Temperature | 60 C (140 F) |
Pricing
OEM / Quantity Pricing Available on Request - Less Services
(Single Unit Pricing. Includes: Integration, Setup,Testing, & Enhanced Support)
| Product # | Description | Price |
|---|---|---|
| PCM-5315 | PCM-5315, Geode LX800 500 MHZ, SODIMM RAM, Compact flash, 2x COM, 4x USB2, 2x LAN, VGA, TTL, LVDS | $285.00 |
| Build to Order | ||
| PCM-5315-AC | PCM-5315-AC, Geode LX800 500 MHZ, SODIMM RAM, Compact flash, 2x COM, 4x USB2, 2x LAN, VGA, TTL, LVDS & Cable Kit | Call |
Peripheral Options
| Product # | Description | Price |
|---|---|---|
| Operating Systems | ||
| SL05x-XON-xx | EMAC OE Linux 5.x for x86 | Free |
| SL013-AMN-00060 | Xenomai Real-Time Extensions (one-time charge) | Call |
| SX300-000-0000D | Windows Embedded Standard 2009 (WES09) & License SOLD ONLY WITH HARD DRIVE OR FLASH DRIVE MEDIA | $125.00 |
| SD622-000-0010 | MS-DOS 6.22 - MSDOS 6.22 LICENSE MS-DOS 6.22 LICENSES are EOL and no longer SOLD, see ROM-DOS 6.22 Part number: SD622-000-0005 as alternate. | Call |
| SD622-000-0005 | ROM DOS 6.22 - ROM DOS 6.22 LICENSE ROM-DOS IS GUARANTEED BY DATALIGHT TO BE 100% COMPATIBLE WITH MS-DOS 6.22 ROM-DOS LICENSES SOLD ONLY WITH HARD DRIVE OR FLASH DRIVE MEDIA | $35.00 |
| SC600-000-0010D | Windows CE 6.0 Pro License SOLD ONLY WITH HARD DRIVE OR FLASH DRIVE MEDIA | $25.00 |
