The PCI-6871 is an all-in-one VIA Eden processor based single board computer (SBC) with a AGP CRT/LCD controller, a PCI 100Base-T Ethernet interfaces, and a PCI audio interface. The PCI-6871 achieves outstanding performance that surpasses any other SBC in its class. In addition, the onboard SSD interface supports type II Compact Flash, with memory capacity above 1 GB.

Features


  • Embedded low power VIA Eden 400/667 MHz
  • Fanless, 0 ~ 60�C (32 ~ 140�F) operation
  • A 10/100Base-T Fast Ethernet Connection
  • Supports Compact Flash (SSD) over 1 GB
  • PCI bus interface
  • PC/104 expansion connector

Overview


The PCI-6871 is an all-in-one VIA Eden processor based single board computer (SBC) with a AGP CRT/LCD controller, a PCI 100Base-T Ethernet interfaces, and a PCI audio interface. The PCI-6871 achieves outstanding performance that surpasses any other SBC in its class. In addition, the onboard SSD interface supports type II Compact Flash, with memory capacity above 1 GB.

Onboard features include two serial RS232/422/485 ports, one multi-mode parallel (ECP/EPP/SPP) port, Pin header for four USB (Universal Serial Bus) ports, a floppy drive controller, and a keyboard-PS/2 mouse interface. The built-in high speed PCI IDE controller supports Ultra DMA/100 mode. Up to four IDE devices can be connected, including large hard disks, CD-ROM drives, and tape backup drives, etc.

The PCI-6871 also features power management to minimize power consumption. It complies with the ACPI standard and supports three types of power saving features: doze, standby, and suspend mode. In addition, the board's watchdog timer can automatically reset the system or generate an interrupt in case the system stops due to a program bug or EMI.

The PCI-6871 is a highly integrated SBC that combines, video, and network functions on a single computer board. It provides up to 1280 x 1024 resolution @ 24 bit color utilizing shared display memory up to 32 Meg. Major onboard devices adopt PCI technology to achieve outstanding computing performance making the PCI-6871 one of the world's best and most powerful all-in-one Single Board Computer.

Specifications


Processor
CPU
Embedded low power VIA Eden
Clock Speed
400 MHz
Processor Misc.

Chipset: VIA VT8806/VT82C686B

Memory
RAM
2x 144-pin SODIMM sockets accept 32MB up to 512MB x2 SDRAM
Primary Flash
1x CompactFlash™ card Type I/II
BIOS/ Bootloader
AWARD 256KB Flash BIOS
Primary IO
Disk Interface
1x FDD, 1x EIDE (UDMA 33/100)
Audio
VIA 82C686 AC97 2.0 (Line-in/Line-out/Mic-in)
Ethernet
IEEE 802.3u 10/100BASE-T Fast Ethernet compatible with on-board RJ-45 connectors Realtek RTL 8139C
USB
2x USB 1.1
Serial Ports
1x RS-232, 1x RS-232/422/485
Primary I/O Misc.
  • DMA: 7 DMA channels (8237 equivalent)
  • I/O Chipset: VT82C686B
  • Parallel port: One bi-directional parallel port. Supports SPP/ECP/EPP modes
  • IR interface: Supports one IrDA Tx/Rx header



Secondary IO
PS/2
Yes
Display
Chipset
VIA TWISTER T with integrated Savage 4 2D/3DVideo Accelerator
LVDS Interface
Supports 2 Channel (2 x 18bit) LVDS interface
Expansion
Bus Expansion
1x PC/104, 1x PCI
Misc
Operating Systems
EMAC OE Linux, XP Embedded (XPE) / WES09, MS-DOS 6.22 / ROM-DOS 6.22
Operating Systems Compatibility
  • Wind River VxWorks
  • QNX Neutrino RTOS
  • RTAI Real-Time Linux

Mechanical and Environmental


Dimensions
Size
7.3" ×4.8" (185mm × 121mm)
Weight
0.3 kg
Power Requirements
Voltage
5 V
Power Misc.

Battery: Lithium battery for data retention

Environmental
Low Operating Temperature0 C (32 F)
High Operating Temperature60 C (140 F)
