SOM-DB5800
- PICMG COM.0R 2.1 Type 6/10 Pin out
- COM Express Basic/ Compact/ Mini module
- VGA, LVDS, MDMI/ DisplayPort Riser Card
- Visible Debug Utility: BIOS 8- Port and Power State
21Spi21122 The SOM-DB5800 is versatile SOM Carrier/Socket board ideal for evaluation and early development work. This Carrier is designed to work with all COM Express type SOMs. The SOM-DB5800 provides access to all the SOM's I/O through on-board connectors.
Although a good deal of customers will want a Carrier that is unique and is designed specifically for their application, the DB5800 when coupled with a COM Express SOM makes for a nice ATX compatible embedded PC.
Features
Compatible Models- Advantech COM Express Basic Modules (125 x 95 mm), COM Express COmpact Modules (95 x 95 mm) and COM Express Mini (84 x 55mm)
LVDS- 18/24-bit single or dual channel
VGA- 1 (D-SUB 15P Female)
HDMI/DP- Up to 3 ports (Expand by SOM-EA20)
Ethernet- 1 Giga LAN
Chipset- Realtek ALC892 HD Audio (Line-in, Line-out, MIC, SPDIF)
PCLe slot- 1 PCle x16 slot/1 PCle x4 slot/1 PCle x 1 slot
Mini-PCle socket- 1
Express Card slot- 2
LPC connector- 1
SATA- 4 (Type B)
USB- 4 USB 2.0 host, include 1 USB Client, 4 USB 3.0
Serial- 4 COM ports, 1 RS-232 (D-SUB 9P), 1 RS-232/422/485, 2 2-Wire RS-232
KB/MS- 1
LPT- 1 (D-SUB 15P)
GPIO- 8
SDIO- 1 (Mux with GPIO)
SMBus- 1
12C-1
SPI- 1
Fan- 2 (1 from Module support iManager Smart Fan)
Port 80- 1
TPM- 1
Power Type- ATX/ AT modes
Operating Temperature- 0 ~ 60 C
Humidity- Operating: 40 C @ 95% relative humidity, non-condensing, Storage: 60 C @ 95% relative humidity, non-condensing
Overview
The SOM-DB5800 is versatile SOM Carrier/Socket board ideal for evaluation and early development work. This Carrier is designed to work with all COM Express type SOMs. The SOM-DB5800 provides access to all the SOM's I/O through on-board connectors.
Although a good deal of customers will want a Carrier that is unique and is designed specifically for their application, the DB5800 when coupled with a COM Express SOM makes for a nice ATX compatible embedded PC.
| Manuals | |
|---|---|
| SOM-DB5800_USER_MANUAL.PDF | Download (PDF) |
| Data Sheets | |
|---|---|
| SOM-DB5800_DS.pdf | Download (PDF) |
Specifications
| Primary IO | |
|---|---|
| GPIO | 8 |
| SDIO | 1 - Mux with GPIO |
| Ethernet | 1 Giga LAN |
| USB | 4 USB 2.0 host, include 1 USB client, 4 USB 3.0 |
| Serial Ports | 4x Serial Ports (1x RS-232 (D-SUB 9P), 1x RS-232/422/485, 2x 2-Wire RS-232) |
| Secondary IO | |
|---|---|
| SPI | 1 |
| I2C | 1 |
| Expansion | |
|---|---|
| Bus Expansion | 1 |
| Misc | |
|---|---|
| SOM Type | COM Express Carrier Boards |
| Misc. | Compatible Models- Advantech COM Express Basic Moduels, COM Express Compact Modules and COM Express Mini |
Mechanical and Environmental
| Dimensions | |
|---|---|
| Size | 12" ×9.6" (304mm × 243mm) |
| Power Requirements | |
|---|---|
| Power Misc. | Power Type- ATX/ AT modes Operating Temperature- 0 ~ 60 C
|
| Environmental | |
|---|---|
| Environmental Misc. | Humidity- Operating: 40 C @ 95% relative humidity, non-condensing, Storage: 60 C @ 95% relative humidity, non-condensing |
Pricing
Pricing correct as of January 2021. Please contact EMAC for Current Pricing and Lead Time. Due to volatility in the electronics industry pricing is subject to change.
OEM / Quantity Pricing Available on Request - Less Services
(Single Unit Pricing. Includes: Integration, Setup,Testing, & Enhanced Support)
| Product # | Description | Price |
|---|---|---|
| SOM-DB5800-00 | SOM-DB5800-00A2E, COM Express Type 6 ATX development board, 4x SATA, 4x COM, 4x USB3, 4x USB2, 1x GbE, 1x VGA, 1x LVDS, HDMI/DP | $392.00 |
| SOM-DB5800-U0 | SOM-DB5800-U0A2E, COM Express Type 10 ATX development board, 4x SATA, 4x COM, 4x USB3, 4x USB2, 1x GbE, 1x VGA, 1x LVDS, HDMI/DP | $445.00 |
