CoM-U15
15cpi711CC43 The CoM-U15, and its accompanying carrier board-ECB-951D, adopt Intel Atom Z530/Z510 processor and Intel System Controller Hub US15W chipset, offering high speed PCI-Express bus interface and serial ATA for your high performance applications requiring high-speed and greater stability. The CoM Express CPU module offers flexibility and time-to-market advantages over a fully customized platform.
Features
- Intel® Atom™ Z530/Z510 Processor
- Onboard DDR2 533 Memory Chip, Max. 1GB
- Intel® System Controller Hub US15W
- Supports 8 USB 2.0 ports
- Gigabit Ethernet
- High Definition Audio Interface
- PATA SSD (Up to 4GB) x 1, SATA II x 1
- Nano Module Size, 84mm x 55mm
Overview
The CoM-U15, and its accompanying carrier board-ECB-951D, adopt Intel Atom Z530/Z510 processor and Intel System Controller Hub US15W chipset, offering high speed PCI-Express bus interface and serial ATA for your high performance applications requiring high-speed and greater stability. The CoM Express CPU module offers flexibility and time-to-market advantages over a fully customized platform.
CoM-U15 supports up to 24-bit single channel LVDS interface and supports onboard DDRII 533 memory chip up to 1GB. A high definition audio interface is available to connect to an audio codec on the carrier board. Moreover, one onboard PATA SSD (Master device) and one SATAII interface are featured giving the user flexibility in storage choices.
| Manuals | |
|---|---|
| com-u15.pdf | Download (PDF) |
| Data Sheets | |
|---|---|
| NanoCOM-U15Datasheet.pdf | Download (PDF) |
Specifications
| Processor | |
|---|---|
| CPU | Intel Atom Z530/Z510 |
| Clock Speed | 1.6 GHz |
| Memory | |
|---|---|
| BIOS/ Bootloader | Award BIOS v8.0 TSOP type, 1MB ROM |
| Memory Misc. |
|
| Primary IO | |
|---|---|
| GPIO | Up to 4 in or 4 out: Multiplexed with 4-bit SDIO |
| Disk Interface | PATA SSD (Up to 4GB) x 1, SATA II x 1 |
| Audio | High definition audio interface |
| Video Out | LCD/DVI or LCD/LCD (via SDVO) Dual-view Displays Supports 24-bit single channel LVDS |
| Ethernet | 10/100/1000Base-TX Ethernet |
| USB | 8 x USB 2.0 compliant ports |
| Secondary IO | |
|---|---|
| Expansion | |
|---|---|
| Bus Expansion | COM Express Type 2 |
| Misc | |
|---|---|
| SOM Type | COM Express Modules |
Mechanical and Environmental
| Dimensions | |
|---|---|
| Size | 3.31" ×2.17" (84mm × 55mm) |
| Environmental | |
|---|---|
| Low Operating Temperature | 0 C (32 F) |
| High Operating Temperature | 60 C (140 F) |
| Upper Operating Humidity | 90% |
| Related Products | |
Pricing
Pricing correct as of January 2021. Please contact EMAC for Current Pricing and Lead Time. Due to volatility in the electronics industry pricing is subject to change.
OEM / Quantity Pricing Available on Request - Less Services
(Single Unit Pricing. Includes: Integration, Setup,Testing, & Enhanced Support)
| Product # | Description | Price |
|---|---|---|
| CoM-U15-A20 | Atom Z510 1.1GHz, US15W, DDRII 1GB, GbE, SATA, USB2.0 | $291.00 |
| CoM-U15-A20-01 | ATOM Z510 1.1GHz,US15W,DDRII 1GB,GbE,4GB SSD,USB2.0 | $375.00 |
| CoM-U15-A20-02 | Atom Z530 1.6GHz,US15W,DDRII 1GB,GbE,SATA,USB2.0 | $371.00 |
| CoM-U15-A20-03 | Atom Z530 1.6GHz,US15W,DDRII 1GB,GbE,4GB SSD,USB2.0 | $455.00 |
